MegaVideo®!G5

Installation Manual!

Models:

1.2 Megapixel

• AV1215PM-S

1080p

• AV2215PM-S

• AV2216PM-S !

3 Megapixel

• AV3215PM-S

• AV3216PM-S

5 Megapixel

• AV5215PM-S

10 Megapixel

• AV10215PM-S

!! ! I !nstallation!Manual

Page | 2 support@arecontvision.com

+1.818.937.0700 877.CAMERA.8 www.arecontvision.com avsales@arecontvision.com

MegaVideo®!G5

Contents

Package Contents!..................................................................................................................................................!3!

System Requirements! !5........................................................................................................................................... !

Installing the Lens! !5.................................................................................................................................................. !

Optional: Connecting Digital I/O!...........................................................................................................................!7!

Camera Power Up!..................................................................................................................................................!8!

Auxiliary Power!.....................................................................................................................................................!10!

Locally Storing Data!.............................................................................................................................................!11!

SD Card Set-up! !.................................................................................................................................................... 11!

Camera Discovery, Setup, and Configuration!..................................................................................................!12!

Network Protocols!................................................................................................................................................!12!

SD Card Tab!.........................................................................................................................................................!15!

SD Card Setup via AV200!...................................................................................................................................!16!

Remote Zoom / Remote Focus via Web Interface!..........................................................................................!18!

Focus Tab!..............................................................................................................................................................!19!

Support! !.................................................................................................................................................................. 20!

!! ! I !nstallation!Manual

Page | 3 support@arecontvision.com

+1.818.937.0700 877.CAMERA.8 www.arecontvision.com avsales@arecontvision.com

MegaVideo®!G5

C ! AUTION

1. not attempt to service a damaged unit yourself. Refer all servicing to qualified service Do

personnel.

2. Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/ANSI, and

with all local codes and authorities having jurisdiction. Wiring should be UL Listed and/or

Recognized wire suitable for the application.

3. Always use hardware e.g. screws, anchors, bolts, locking nuts etc. which are compatible with

mounting surface and of sufficient length and construction to insure a secure mount.

Package Contents

This equipment should be unpacked and handled with care. The original packaging is the safest

container in which to transport the unit and can be used if returning the unit for service. The packaging

contains:

• One (1) Arecont Vision MegaVideo® G5 Camera

• One (1) Rubber gasket (preinstalled on the camera)

• One (1) CD containing software and user manual se key required for recording) (licen

• One (1) C to CS lens adapter (lens sold separately)

• One (1) 0.5mm lens spacer ring

• One (1) 6-position external power & IO plug

• One (1) 0.05” hex L-Key

Product specificaties

Merk:	Arecont Vision
Categorie:	Bewakingscamera
Model:	AV3216PM-S
Kleur van het product:	Black, Metallic
Soort:	IP-beveiligingscamera
Bluetooth:	Nee
Vormfactor:	Doos
Ondersteuning voor plaatsing:	Binnen & buiten
Connectiviteitstechnologie:	Bedraad
Ethernet LAN:	Ja
Montagewijze:	Plafond/muur
Maximum resolutie:	- Pixels
Totaal aantal megapixels:	3 MP
Type stroombron:	Power over Ethernet (PoE)
Stroomuitvoer (volt):	12, 48
Minimale belichting:	- Lux
Aantal cameras:	1
Geïntegreerde geheugenkaartlezer:	Ja
Compatibele geheugenkaarten:	SDHC
Ingebouwde HDD:	Nee
Video bewegings-detectie:	Ja
Zoomcapaciteit:	Ja
Focus:	Gemotoriseerd
Type beeldsensor:	WDR
Maximaal 30 frames per seconde:	21 fps
Dag/nacht modus:	Ja
Methode voor streaming:	Multicast
Aantal sensoren:	1
Bitratecontrole:	Constante bitsnelheid (CBR)
Wide Dynamic Range (WDR):	Ja
Wifi:	Nee
AC-ingangsspanning:	24 V
Privézone maskeren:	Ja
