MegaBall®!G2

Installation Manual!

Models:

1.2 Megapixel

• AV1245PMIR-SB-LG

1080p

• AV2245PM-D-LG

• AV2245PM-B-LG

• AV2245PMIR-SB-LG

• AV2245PMIR-SBA-LG

• AV2246PM-D-LG

• AV2246PM-B-LG

• AV2246PMIR-SB-LG

3 Megapixel

• AV3245PM-D-LG

• AV3245PM-B-LG

• AV3245PMIR-SB

• AV3246PM-D-LG

• AV3246PM-B-LG

• AV3246PMIR-SB-LG

• AV3246PMIR-SBA-LG

5 Megapixel

• AV5245PM-D-LG

• AV5245PM-B-LG

• AV5245PMIR-SB-LG

• AV5245PMIR-SBA-LG

• AV5245DN-01-D-LG

• AV5245DN-01-DA-LG

!! ! Installation!Manual!

Page | 2 support@arecontvision.com

+1.818.937.0700 877.CAMERA.8 www.arecontvision.com avsales@arecontvision.com

MegaBall®!G2

Contents

Package Contents!..................................................................................................................................................!4!

Dome In-ceiling Mount!.........................................................................................................................................!11!

Dome Pendant Mount!..........................................................................................................................................!15!

Dome Surface Mount!...........................................................................................................................................!16!

Installing the Bubble (optional)!...........................................................................................................................!18!

Wall Mount!.............................................................................................................................................................!19!

Pole Mount!............................................................................................................................................................!20!

Corner Mount!........................................................................................................................................................!22!

Electrical Box Adapter!.........................................................................................................................................!24!

Adjusting the Focus on Panomorph Lens Cameras (DN-01 models)!...........................................................!29!

Dewarping from ImmerVision Demo viewer (DN-01 models)!........................................................................!31!

Optional: Connecting Digital I/O!.........................................................................................................................!34!

Camera Discovery, Setup, and Configuration!..................................................................................................!39!

Network Protocols!................................................................................................................................................!39!

Locally Storing Data!.............................................................................................................................................!40!

SD Card Set-up!....................................................................................................................................................!40!

SD Card Tab!.........................................................................................................................................................!43!

SD Card Setup via AV200!...................................................................................................................................!44!

Refined Remote Focus!........................................................................................................................................!47!

Adjusting P-iris (PM models only)!......................................................................................................................!48!

Mounting Templates!............................................................................................................................................!50!

Support!..................................................................................................................................................................!52!
