HPS10 models

4065452, 4842214 &

5207971

HPA10 models

5374506, 5374507,

5374512 & 5374513

HPV10 models

5374508 & 5374510

ConguraonEnclosed RoomFully Louvered Door

Upper and Lower Louvers in Door

(Note 1,2)

Upper Louver and Undercut Door

(Note 1,3,4)

Inlet or

Outlet Ducng and a Single

Louver or Undercut Door (Note

1,3,4,5)

Inlet and Outlet Ducng

(Note 5)

Minimum Space (FT

3

)

450848484

Space Example

L x W x H (FT)

6 x 7.5 x 103 x 2.8 x 103 x 2.8 x 103 x 2.8 x 10

450 

3

enclosed room size is 35% smaller than other manufacturers require

Note 1: Minimum louver size is 130 in

2

free area

each.

Note 2: When two louvers are installed, install one louver at the top of the heater and the other close to the oor.

Note 3: Undercut door should have a minimum of 0.75" clearance. (minimum 18 in

2

air gap)

Note 4: When one louver is installed, install the louver in a locaon close to the top of the heater.

Note 5: This heater supports mulple duct diameters as well as rigid and ex ducng opons. See manual for more informaon.

HP10 models

Lowe's Items:

816193 & 816194

ConguraonEnclosed RoomFully Louvered Door

Upper and Lower Louvers in Door

(Note 1,2)

Upper Louver and Undercut Door

(Note 1,3,4)

Inlet or

Outlet Ducng and a Single

Louver or Undercut Door (Note

1,3,4,5)

Inlet and Outlet Ducng

(Note 5)

Minimum Space (FT

3

)

450848484

Space Example

L x W x H (FT)

6 x 7.5 x 103 x 2.8 x 103 x 2.8 x 103 x 2.8 x 10

450 

3

enclosed room size is 35% smaller than other manufacturers require

Note 1: Minimum louver size is 130 in

2

free area

each.

Note 2: When two louvers are installed, install one louver at the top of the heater and the other close to the oor.

Note 3: Undercut door should have a minimum of 0.75" clearance. (minimum 18 in

2

air gap)

Note 4: When one louver is installed, install the louver in a locaon close to the top of the heater.

Note 5: Ducng these models requires adapter kit 100234320. Duct with 8" ex duct. Maximum 50 equivalent feet for total of inlet and outlet ducng.

No minimum space requirementNo minimum space requirement

No minimum space requirementNo minimum space requirement

Venlaon Guidelines for Professional Installers
