- 1 -
Product names listed herein are trademarks of AS America, Inc.
© AS America, Inc. 2013
RECOMMENDED TOOLS
M965030 REV.1.6 (4/15)
ROUGHING-IN DIMENSIONS
CARE INSTRUCTIONS:
Certied to comply with ANSI A112.18.1M
ASSE 1016
To ensure that your installation proceeds smoothly, please read
these instructions carefully before you begin.
Thank you for selecting American Standard...
the benchmark of fine quality for over 100 years.
INSTALLATION
INSTRUCTIONS
T42073X Series
PORTSMOUTH
®
CENTRAL THERMOSTAT
LESS VOLUME CONTROL
TRIM KIT
H
O
T
C
O
L
D
Flat Blade Screwdriver
Phillips Screwdriver
242mm
(9-5/8")
151mm
(5-7/8")
86mm
(3-3/8")
25mm
(1")
34mm
(1-3/8")
193mm
(7-5/8")
LEVER
HANDLE
CROSS
HANDLE
150mm
(5-7/8")
48mm to 68mm
(2" to 2-5/8")
R510
1/2 NPT
R530
3/4 NPT
R510
1/2 NPT
R530
3/4 NPT
• To keep your new faucet looking new, please follow
these simple care instructions:
DO:• Simply rinse the faucet clean with clear water.
• Dry the faucet with a soft cotton cloth.
DO NOT:
• Do not use any abrasive cleaners, cloths, or
paper towels.
• Do not use any cleaning agents containing
acids, polish abrasives, or harsh cleaners or
soaps.
Regular and routine cleaning will reduce the need for
heavy cleaning and polishing. If heavy cleaning is
required, the following procedures are recommended:
• Remove as much surface dirt and lm using clear
water and soft cotton cloth (as described above).
• Use any of the following to remove tough surface
lm and build-up:
• Mild liquid detergents
• Clear ammonia free liquid glass cleaners
• Non-acidic, non-abrasive gentle liquid or fully
dissolved powder cleansers mixed according to
manufacturers directions.
• Non-abrasive liquid polishers
Once clean, rinse faucet again with clear water to
thoroughly remove cleaner or polish and blot dry with
a soft cotton cloth.
Failure to follow these care instructions may damage
the Faucet’s finish.
