Pagina 1/12
American DJ
4295 Charter Street
Los Angeles CA. 90058
www.americandj.com
Rev. 9/07
User Instructions
© ®American DJ - www.americandj.com - DJ Spot 250™ Instruction Manual Page 2
DJ Spot 250™
Table of Contents
General Instructions....................................................................2
Customer Support.......................................................................3
Safety Precautions......................................................................4
Features.........................................................................5
Registration......................................................................5
Controls and Functions..............................................................6
Set-Up.............................................................................9
System Menu............................................................................12
Operating Modes.......................................................................16
Fuse and Lamp Replacement...................................................18
DMX Traits.................................................................................20
Gobos..................................................................................21
Cleaning..................................................................22
Trouble Shooting.......................................................................22
Warranty....................................................................................23
Specifications....................................................................24
To optimize the performance of this product, please read these operating
instructions carefully to familiarize yourself with the basic operations of
this unit. These instructions contain important safety information regard-
ing the use and maintenance of this unit. Please keep this manual with
the unit, for future reference.
Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures war-
ranty. In the unlikely event your unit may require service please contact
American DJ .®
During operation the housing may become extremely hot. Avoid touch-
ing the unit with bare hands while in use.
American DJ
® will not accept any liability for any resulting damages
caused by the non-observance of this manual or any unauthorized
modifi cation to this unit.
DJ Spot 250™ General Instructions
Unpacking: Thank you for purchasing the DJ Spot 250™ by Ameri-
can DJ®. Every DJ Spot 250™ has been thoroughly tested and has
been shipped in perfect operating condition. Carefully check the ship-
ping carton for damage that may have occurred during shipping. If the
carton appears to be damaged, carefully inspect your fi xture for any
damage and be sure all equipment necessary to operate the unit has
arrived intact. In the event damage has been found or parts are miss-
ing, please contact our toll free customer support number for further
instructions. Please do not return this unit to your dealer without con-
tacting customer support fi rst.
Introduction: The DJ Spot 250™ is a six channel, moving head, intel-
ligent DMX fixture. The fixture can operate in three different operating
modes; stand alone, sound-active, or in a Master/Slave configuration.
The DJ Spot 250™ comes with several built in programs and is best
used in multiples of four. For best results use fog or special effects
smoke to enhance the beams projections.
During the initial start-up or use of this product a light smoke or
smell may arise from the unit. This is a normal process and is
cause by the heat associated with the lamp.
Customer Support: American DJ provides a toll free customer ®
support line, to provide help and to answer any question should you
encounter problems during your set up or initial operation. You may
also visit us on the web at www.americandj.com for any comments or
suggestions. Service Hours are Monday through Friday 9:00 a.m. to 5:
00 p.m. Pacifi c Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2610
E-mail: support@americandj.com
To purchase parts online visit http://parts.americandj.com
Warning! To prevent or reduce the risk of electrical shock or fi re, do
not expose this unit to rain or moisture.
Warning! This may cause severe eye damage. Avoid looking directly
into the light source at all times!
DJ Spot 250™ General Information
For Your Own Personal Safety, Please Read and Understand This
Manual Completely Before You Attempt To Install Or Operate
This Unit!
• To reduce the risk of electrical shock or fi re, do not expose this unit
rain or moisture
• Do not spill water or other liquids into or on to your unit.
• Be sure that the local power outlet match that of the required volt-
age for your unit.
• Do not attempt to operate this unit if the power cord has been
frayed or broken.
• Do not attempt to remove or break off the ground prong from
the electrical cord. This prong is used to reduce the risk of electrical
shock and fi re in case of an internal short.
• Disconnect from main power before making any type of connection.
• Do not remove the cover under any conditions. There are no user
serviceable parts inside.
• Never operate this unit when it’s cover is removed.
• Always be sure to mount this unit in an area that will allow proper
ventilation. Allow about 6” (15cm) between this device and a wall.
• Do not attempt to operate this unit, if it becomes damaged.
• This unit is intended for indoor use only, use of this product out-
doors voids all warranties.
• Always mount this unit in safe and stable matter.
• Power-supply cords should be routed so that they are not likely to
be walked on or pinched by items placed upon or against them,
paying particular attention to cords at plugs, convenience recep-
tacles, and the point where they exit from the appliance.
• Cleaning -The fixture should be cleaned only as recommended by
the manufacturer. See page 22 for cleaning details.
• Heat -This fixture should be situated away from heat sources such
as radiators, heat registers, stoves, or other appliances (including
amplifiers) that produce heat.
• The fixture should be serviced by qualified service personnel when:
A. Objects have fallen, or liquid has been spilled into the appliance.
B. The appliance has been exposed to rain or water.
C. The appliance does not appear to operate normally or exhibits a
marked change in performance.
DJ Spot 250™ Safety Precautions
© ®American DJ - www.americandj.com - DJ Spot 250™ Instruction Manual Page 4© ®American DJ - www.americandj.com - DJ Spot 250™ Instruction Manual Page 3
© ®American DJ - www.americandj.com - DJ Spot 250™ Instruction Manual Page 5
• Micro-Stepping Motors for Smooth Color and Gobo Transitions
• DMX-512 Protocol Compatible (Uses Six DMX Channels)
• Independent Gobo and Color Wheels
• 10 Gobos + Spot
• 7 Colors, Plus White - With Rainbow
• Color Correction Filter for a Crisp White Color
• Strobing in All Colors and Gobo Shake
• 3 Operating Modes - Master/Slave; Stand Alone, Sound Active;
Universal DMX-512
• Internal Microphone
• ZB-EHJ 24v/250w
• Manual Focus Lens
• 540˚ Pan Movement
• 265˚ Tilt Movement
• Digital Display for Address and Function Setting
• High Velocity Fans for continuous use (no duty cycle)
DJ Spot 250™ Features
The DJ Spot 250™ carries a one year limited warranty. Please fill out
the enclosed warranty card to validate your purchase. All returned
service items whether under warranty or not, must be freight pre-paid
and accompany a return authorization (R.A.) number. The R.A. number
must be clearly written on the outside of the return package. A brief
description of the problem as well as the R.A. number must also be
written down on a piece of paper and included in the shipping carton.
If the unit is under warranty, you must provide a copy of your proof of
purchase invoice. You may obtain a R.A. number by contacting our
customer support team on our toll free customer support number. All
packages returned to the service department not displaying a R.A.
number on the outside of the package will be returned to the shipper
at the shippers cost.
DJ Spot 250™
Product
Registration
© ®American DJ - www.americandj.com - DJ Spot 250™ Instruction Manual Page 6
8888
ESC DOWN UP
ENTER
DJ Spot 250™ Controls and Functions
REAR
FRONT
1
3 4 5 6 7
2
11
9
8
8
8
7
10
12
13
14
