This is an abbreviated programming manual addressing basic program settings for an IXG Series system using the

IXG Support Tool.

A complete set of instructions (IXG Operation Manual / IXG Support Tool Setting Manual)can be found at

www.aiphone.com/IXG, along with additional literature and media.

ATTENTION:

IXG SERIES

IP Multi-Tenant Video Intercom

If updating dimensions, be sure to update the GLC layer too.

Please refer to the Product Dimensions Master located here:

H:\Engineering Services\Product Dimensions Master Document\Product Dimensions Master.xlsx

IXG-2C7

8-15/16"1"

5-13/16"

If updating dimensions, be sure to update the GLC layer too.

Please refer to the Product Dimensions Master located here:

H:\Engineering Services\Product Dimensions Master Document\Product Dimensions Master.xlsx

IX-DV

IX-DV

8-1/8"

4-1/2"1-3/4"

If updating dimensions, be sure to update the GLC layer too.

Please refer to the Product Dimensions Master located here:

H:\Engineering Services\Product Dimensions Master Document\Product Dimensions Master.xlsx

IXG-DM7

7-3/16"

1-1/2"1/2"

13-11/16"

Quick Start Programming Guide

IXG Support Tool version 5.0.1.0

02/25

Table of Contents

Page 2 General Overview

Page 3-10 Creating a New System

Page 11 Mobile App Integration

Page 12 Property Manager Account Creation

Page 13 Entrance Station Settings

Page 14 Station Partitioning

Page 15 Additional Settings

Page 16-17 IXW-MA(A) Programming

Pages 18-19 Updating Station Firmware

Pages 20-23 Network Security Summary

Page 24 Notes
