1 Startup Manual
UNOP-1000K
PCIe Expansion Card for UNO-4673A/4683, ECU-4784
Overview
UNOP-1000 equips standard expansion inter-
faces:
UNOP-1000K: PCIe Expansion card for UNO-
4673A, UNO-4683 and ECU-4784
NOTE:
1. The UNO-4673A/4683 only provides PCIe re-
sources on Slot1, that means the PCIe card
can only work on Slot 1.
2. The ECU-4784 provides PCIe resources on
Slot1 and Slot2, that means the PCIe card
can work on Slot1 and Slot2.
Before installing 3rd party plug-in cards, refer to
UNO-4673A/4683, ECU-4784 user manual for
total thermal/ power consumption information.
Diagram
Packing List
Before installation, please make sure that you
have received the following:
• 1 x UNOP-1000K unit
• 1 x Front Panel
• 1 x Holder
• 2 x M3 screws
• 1x ROHS LIST
• 1 x UNOP-1000 startup manual
• 1 x warranty card
If anything is missing or damaged, contact your
distributor or sales representative immediately.
Notes
For more information on this and other Advan-
tech
products, please visit our websites at:
http://www.advantech.com/products/ProView/
For technical support and service:
http://www.advantech.com/support/
This startup manual is for UNOP-1000K
Part No: 2003P100012nd Edition
June 2016
STARTUP MANUAL
User Manual
For more detailed information, please refer to the
full manual which can be found on the Advan-
tech’s website.
Installation
Follow the exploded diagrams below for plug-in
card installation
• UNOP-1000K
