PCE-5B19-00 Startup Manual 1

Before card installation, please ensure that the following

items have been shipped:

• PCE-5B19-00A1E startup manual first edition

• M4*6*0.7 round screws P/N: 1939000410

• Two-year quality warranty card P/N: 2190000902

If any of the items are missing or damaged, please contact

your local distributor or sales representative immediately.

Standard Functions

• PICMG 1.3 slots: PCE-5B19-00A1Esupports PCE-5000

and 7000 series CPU boards

• PCIe slots: 17 PCIe x16 and 1 PCIe p1-x4

*To enquire about memory, I/O, or IRQ resource limita-

tions, please contact your local Advantech office or FAE

for further support.

• PCIe switch: Four 24-port/96-lane PCIe Gen3.0 switch

for reducing data latency.

• USB (2.0) ports: Four USB ports serving as pin headers

Mechanical and Environment

• Dimensions: 327.66 x 417 mm

• Power supply voltage: +12 V, +5 V, -12 V, -5 V, +3.3 V,

5 VSB

• Power requirements: Refer to CPU board, add-on card,

and peripheral documentation

• Operating temperature: 0 ~ 60 °C (depending on the

system thermal solution)

• Weight: 1.22 kg (weight of board)

PCE-5B19-00A1E PICMG1.3 Backplane: 19-slot BP

for 20-slot chassis, 17 x PCIe x16, 1 x PCIe x4

Startup Manual

The backplane features several connectors and jumpers

that facilitate system configuration according to application.

The function of each connector and jumper is listed below.

Connectors

Part ReferenceFunction

SHBA1 ~ SHBD1PICMG 1.3 CPU board slot

P1PCIEX1 PCIe x16 slot driven p1-x4 PCIe link

P2PCIEX16_1~2PCIe x16 slot driven x16 PCIe link

P3PCIEX16_1~5PCIe x16 slot driven x16 PCIe link

P4PCIEX16_1~5PCIe x16 slot driven x16 PCIe link

P5PCIEX16_1~5PCIe x16 slot driven x16 PCIe link

EATXPWR1ATX 2.0 24-pin power connector

EATX12V1~4ATX 12 V 8-pin power connector

PWR_4P1

ATX 5 V and 12 V 4-pin power

connector

PWR3V1~23.3 V Auxiliary power connector

SMBUS1 &

SMBUS2

Chassis sensor board connectors

FAN1 ~ FAN5Fan connectors

HSFAN1~2Cooler FAN power connectors

VOLT1 Alarm board/CMM power connector

FANDEC1 Fan detector connector

JFP1 Power and reset button connector

IPMB1 IPMB connector

USB12 USB connector

USB34 USB connector

JP2COMP1/JP-

3COMP1/

JP4COMP1/JP-

5COMP1

Support for non-compliant Gen-1

endpoints enabled

Note: This feature should only be

enabled if a non-compliant Gen-1

device does not linkup when the

data rate identier bits are set.

JP2GEN1/

JP3GEN1/JP-

4GEN1/JP5GEN1

PCIe data rate select

Connectors and Jumpers Packing List

For more information regarding this or other Advantech

products, please visit our website at

http://www.advantech.com

http://www.advantech.com/eplatform

For technical support and service, please visit our

support website at

http://www.advantech.com/support/

This manual is for PCE-5B19-00A1E.

Part No. 20025B1900

Printed in China

Edition 1

January 2015
