User Manual

EKI-7428 Series

24GE+4G Combo/24GE PoE+4G

Combo Port L2 Managed Switch

ii EKI-7428 Series User Manual

The documentation and the software included with this product are copyrighted 2006

by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right

to make improvements in the products described in this manual at any time without

notice. No part of this manual may be reproduced, copied, translated or transmitted

in any form or by any means without the prior written permission of Advantech Co.,

Ltd. Information provided in this manual is intended to be accurate and reliable.

However, Advantech Co., Ltd. assumes no responsibility for its use, nor for any

infringements of the rights of third parties, which may result from its use.

Acknowledgements

Intel and Pentium are trademarks of Intel Corporation.

Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp.

All other product names or trademarks are properties of their respective owners.

Product Warranty (5 years)

Advantech warrants to you, the original purchaser, that each of its products will be

free from defects in materials and workmanship for five years from the date of

purchase.

This warranty does not apply to any products which have been repaired or altered by

persons other than repair personnel authorized by Advantech, or which have been

subject to misuse, abuse, accident or improper installation. Advantech assumes no

liability under the terms of this warranty as a consequence of such events.

Because of Advantech’s high quality-control standards and rigorous testing, most of

our customers never need to use our repair service. If an Advantech product is

defective, it will be repaired or replaced at no charge during the warranty period. For

out of-warranty repairs, you will be billed according to the cost of replacement

materials, service time and freight. Please consult your dealer for more details.

If you think you have a defective product, follow these steps:

1. Collect all the information about the problem encountered. (For example, CPU

speed, Advantech products used, other hardware and software used, etc.) Note

anything abnormal and list any on screen messages you get when the problem

occurs.

2. Call your dealer and describe the problem. Please have your manual, product,

and any helpful information readily available.

3. If your product is diagnosed as defective, obtain an RMA (return merchandize

authorization) number from your dealer. This allows us to process your return

more quickly.

4. Carefully pack the defective product, a fully-completed Repair and Replacement

Order Card and a photocopy proof of purchase date (such as your sales receipt)

in a shippable container. A product returned without proof of the purchase date

is not eligible for warranty service.

5. Write the RMA number visibly on the outside of the package and ship it prepaid

to your dealer.

Part No. XXXXXXXXXX Edition 1

Printed in Taiwan April 2018

Product specificaties

Merk:	Advantech
Categorie:	Schakelaar
Model:	EKI-7428G-4CPI-AE
Kleur van het product:	Zwart
Gewicht:	3800 g
Breedte:	438 mm
Diepte:	259.2 mm
Hoogte:	43.6 mm
Materiaal behuizing:	Metaal
Internationale veiligheidscode (IP):	IP30
LED-indicatoren:	Activity, Collision, Link, Speed
Vormfactor:	1U
Certificering:	CE, FCC, RoHS
Duurzaamheidscertificaten:	RoHS
Ingangsspanning:	48 V
Netwerkstandaard:	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Ondersteunde beveiligingsalgoritmen:	HTTPS, SNMPv3, SSH
Temperatuur bij opslag:	-40 - 85 °C
Luchtvochtigheid bij opslag:	10 - 95 procent
Rack-montage:	Ja
Elektromagnetische compatibiliteit:	EN 61000-4-2 (Level 3), EN 61000-4-3 (Level 3), EN 61000-4-4 (Level 3), EN 61000-4-5 (Level 3), EN 61000-4-6 (Level 3), EN 61000-4-8 (Level 3)
Mean time between failures (MTBF):	424517 uur
Power over Ethernet (PoE):	Ja
Switchingcapaciteit:	56 Gbit/s
MAC-adrestabel:	8000 entries
Switch type:	Managed
Aantal basis-switching RJ-45 Ethernet-poorten:	28
Switch-laag:	L2
Type basis-switching RJ-45 Ethernet-poorten:	Gigabit Ethernet (10/100/1000)
Packet buffergeheugen:	4.1 MB
Jumbo Frames ondersteuning:	Ja
Koperen ethernetbekabelingstechnologie:	10BASE-T, 100BASE-T, 1000BASE-T
Auto-negotiation:	Ja
Stroomverbruik (typisch):	20 W
Bedrijfstemperatuur (T-T):	-40 - 70 °C
Relatieve vochtigheid in bedrijf (V-V):	10 - 95 procent
Totaal Power over Ethernet (PoE)-budget:	685 W
Verzending snelheid:	41.6 Mpps
Jumbo frames:	9216
Hoeveelheid Power over Ethernet (PoE) ports:	24
Vezel-optische connector:	SFP
Aantal Combo SFP-poorten:	4
Multicast MAC adrestabel:	8000 entries
Transmissie afstand (max):	110 km
