EKI-2428G-4FA

Rackmount Ummanaged Redundant Industrial Switch

Specifications

The EKI-2428G is an unmanaged switch with 24

Gigabit ports and 4 Gigabit SFP ports that can

provide users with abundant ports to connect

many devices. It is designed for rack-mount

installation, and suitable for edge to core

networks.

Before installation, please make sure that you

have received the following:

•

1 x EKI-2428G-4FA Rackmount Ummanaged

Switch

•

1 x Startupmanual

If anything is missing or damaged, contact your

distributor or sales representative immediately.

General

•

Compatibility: IEEE 802.3, 802.3u, 802.3x,

802.3ab, 802.3z

• LAN: 10/100/1000 Base-TX

•

SFP: Up to 110 km (depends onSFP)

•

Ethernet RJ-45 Distance: Up to 100 m

•

Connectors:

24 x 10/100/1000Base-T/TX RJ-45

4 x SFP(mini-GBIC) port

•

PowerRequirements:

100~240V single AC power input

•

Power Consumption: 18W

•

Dimensions (W x H x D): 442 x 44 x 211.1mm

•

Enclosure: Metal shell with solid mountingkits

•

Operating Temperature: 0 ~ 55°C (32 ~ 131°F)

•

Storage Temperature: -20 ~ 70°C (-4 ~ 158°F)

•

Operating Humidity: 10 ~ 95%(non-condensing)

•

Storage Humidity: 10 ~95% (non-condensing)

•

EMC: CE FCC ClassA

•

Warranty:5years

For more detailed information, please refer to the

full manual which can be found on the Advan-

tech’s website.

User Manual

Notes

For more information on this and other Advantech

products, please visit ourwebsites at:

http://www.advantech.com/products

For technical support and service:

http://www.advantech.com/support/

This startup manual is for EKI-2428G-4FA

Part No:

1st Edition

Dec 2017

Packing List

Overview

STARTUP

MANUAL

1 Startup Manual
