Pagina 1/2
Recommended Accessories
Power Supply for #BB-USH204-B
40W, 12V, DIN Rail, Plastic
Model 96PSD-A40W12-MM
Power Supply for #BB-USH207-B
60W, 24V, DIN Rail, Plastic
Model 96PSD-A60W24-MM
USB 3.0 Cable
3 ft. (0.91 m)
Model BB-USB3AMBM-3FT
Document Number: BB-USH20x_ qsg1223
B ore you begin, be ef
sure you have the following:
BB-USH204-B or
BB-USH207-B
Industrial 4 or 7 Port USB 3.0 Hub
Fast and sy on the web:ea
www.advantech.com
+ Industrial USB Hub (included)
+ USB 3.0 Type A to B Cable, 2m (included)
+ DIN Rail & Wall Mount Kit (included)
+ Terminal Block (included)
+ Power Supply (required, sold separately)
+ USB Cable (additional, sold separately)
QUICK START
GUIDE
Pro ct Overviewdu
Power
1
3-Pin Termi l Blockna
2
Plug the included ter nal block into the b’s ter nalmi hu mi
Assignment ta e low for wiring the power bl be adapter
(power apter noad t included).
Upstream Port
(USB Type B)
Power LED
Downstream Ports
(USB Type A)
3-pin
Terminal B cklo
DC Power Jack
USB 3.0 HUB - SPECIFICATIONS
US 3.0 CompliantB
Enclosure
USB Specification
Industr l gradia e metal housing
ESD Protection 15KV, USB interface
Power Input 9 to 30V DC
Dimensions
5.5 x 2.7DW x 1.0H in
(139.7W x 68.6D x 25.4H mm)
Mounting Wall or DIN rail mount (kit included)
BB-USH204-B
Pin Assignment
1V+ (9- DC)30V
2V-
3Earth Ground
USB Type B Port - Pin Assignment
Pin Pin
1 6Vbus StdA-SSTX+
2 7D- GND_DRAIN
3 8D+ StdA_SSRX-
4 9GND StdA_SSRX+
5StdA-SSTX- Shell Shi del
USB 3.0 Type B Upstream Port
3
Hardware Installation
4
Mount your hub on the wall or DIN rail, f i needed.
DI Rail MountingN
Use the cluded screw o install the DIN rail kiin s t t to
the hub.
Inser the top ot f the DIN rail clip onto the DIN rail
track, t n gently push the bottom ohe f the hub to
secure i o the DIN rail track.t t
Wal Mount Plate Mountingl
Use the ovided wall mounpr t pl to mounate t the hub to
the wall.
Wall
Wall Mount
Plate
Wall Mount
Plate
Wall
DIN-Rail kit
123
1
4
2
5 9
4
The USB 3.0 hub requires a 9-30 VDC external power
source to work (not included, sold separately).
A 30 Watt or greater power supply is recommended for
BB-USH204-B.
A 45 Watt or greater power supply is recommended for
BB-USH207-B.
Power up the USB hub through either the DC power
jack or 3-pin terminal block.
