PCE-3B03-01 Startup Manual 1

Before installing your card, please ensure that the following

items have been shipped:

•PCE-3B03-01 User Manual 1st edition p/n: 20063B0310

•Two-year quality warranty card p/n: 2190000902

If either of the above items are missing or damaged, please

contact your distributor or sales representative immediately.

PCE-3B03-01 Backplane: 3 Slot PICMG1.3 BP, PCI*1,

PCIe x16*1

Startup Manual

Standard Functions

•PICMIG 1.3 slots: PCE-3B03-01 supports PICMG1.3

half-sized SHB

•PCIe slots: PCE-3B03-01 supports one PCIe x16 and

one PCI

Mechanical and Environmental

•Dimensions: 173 x 86.3 mm

•Power supply voltage: +12 V, +5 V, -12 V, +3.3 V, and

+5VSBY

•Power requirements: Refer to the CPU board, add-

on card, and peripherals

•Operating temperature: 0 ~ 60 °C

•Weight: 0.104 kg (weight of board)

Specications

Packing List

For more information about this or other Advantech

products, please visit our website at

http://www.advantech.com

http://www.advantech.com/eplatform

For technical support and service, please visit our

support website at

http://support.advantech.com/

This manual is for the

PCE-3B03-01

series, Revision A1.

Part No. 20063B0310

Printed in China

1st Edition

September 2014
