Quad Phase GO
Bekijk gratis de handleiding van Adj Quad Phase GO (12 pagina’s), behorend tot de categorie Niet gecategoriseerd. Deze gids werd als nuttig beoordeeld door 2 mensen en kreeg gemiddeld 4.9 sterren uit 1.5 reviews. Heb je een vraag over Adj Quad Phase GO of wil je andere gebruikers van dit product iets vragen? Stel een vraag
Pagina 1/12
Rev. 3/14
User Instructions
ADJ Products, LLC - www.adj.com - Quad Phase Go Instruction Manual Page 2
Quad Phase Go General Information
Unpacking: Thank you for purchasing the Quad Phase Go by ADJ
Products, LLC. Every Quad Phase Go has been thoroughly tested and
has been shipped in perfect operating condition. Carefully check the
shipping carton for damage that may have occurred during shipping.
If the carton appears to be damaged, carefully inspect your xture for
any damage and be sure all equipment necessary to operate the unit
has arrived intact. In the event damage has been found or parts are
missing, please contact our toll free customer support number for fur-
ther instructions. Please do not return this unit to your dealer without
contacting customer support rst.
Introduction: The Quad Phase Go is a rechargeable lithium battery
powered, DMX intelligent, moonflower effect. The fixture can operate
in as a stand alone fixture or in a Master/Slave configuration. The Quad
Phase Go has two operating modes; sound active and DMX Control.
For best results use fog or special effects smoke to enhance the beams
projections.
Customer Support: ADJ Products, LLC provides a toll free cus-
tomer support line, to provide help and to answer any question should
you encounter problems during your set up or initial operation. You
may also visit us on the web at www.adj.com for any comments or
suggestions. Service Hours are Monday through Friday 8:00 a.m. to
4:30 p.m. Pacic Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2941
E-mail: support@adj.com
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
Caution! This may cause eye damage. Avoid looking directly into the
light source. Use sensible precaution.
For Your Own Personal Safety, Please Read and Understand This
Manual Completely Before You Attempt To Install Or Operate
This Unit!
• To reduce the risk of electrical shock or re, do not expose this unit
rain or moisture
• Do not spill water or other liquids into or on to your unit.
• Be sure that the local power outlet match that of the required volt-
age for your unit.
• Do not attempt to operate this unit if the power cord has been
frayed or broken.
• Do not attempt to remove or break o the ground prong from
the electrical cord. This prong is used to reduce the risk of electrical
shock and re in case of an internal short.
• Disconnect from main power before making any type of connection.
• Do not remove the cover under any conditions. There are no user
serviceable parts inside.
• Never operate this unit when it’s cover is removed.
• Always be sure to mount this unit in an area that will allow proper
ventilation. Allow about 6” (15cm) between this device and a wall.
• Do not attempt to operate this unit, if it becomes damaged.
• This unit is intended for indoor use only, use of this product out-
doors voids all warranties.
• Always mount this unit in safe and stable matter.
• Power-supply cords should be routed so that they are not likely to
be walked on or pinched by items placed upon or against them,
paying particular attention to cords at plugs, convenience recep-
tacles, and the point where they exit from the appliance.
• Cleaning -The fixture should be cleaned only as recommended by
the manufacturer. See page 20 for cleaning details.
• Heat -This fixture should be situated away from heat sources such
as radiators, heat registers, stoves, or other appliances (including
amplifiers) that produce heat.
• The fixture should be serviced by qualified service personnel when:
A. Objects have fallen, or liquid has been spilled into the appliance.
B. The appliance has been exposed to rain or water.
C. The appliance does not appear to operate normally or exhibits a
marked change in performance.
Quad Phase Go Safety Precautions
ADJ Products, LLC - www.adj.com - Quad Phase Go Instruction Manual Page 4ADJ Products, LLC - www.adj.com - Quad Phase Go Instruction Manual Page 3
Quad Phase Go Features
Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures
warranty. In the unlikely event your unit may require service please
contact ADJ Products, LLC.
ADJ Products, LLC will not accept any liability for any resulting dam-
ages caused by the non-observance of this manual or any unauthor-
ized modication to this unit.
Quad Phase Go Handling Precautions
Quad Phase Go Warranty Registration
The Quad Phase Go carries a year (730 days) limited warranty. 2
Please fill out the enclosed warranty card to validate your purchase
and warranty. You may also register your product online at www.
americandj.com. All returned service items whether under warranty or
not, must be freight pre-paid and accompany a return authorization
(R.A.) number. If the unit is under warranty you must provide a copy
of your proof of purchase invoice. Please contact ADJ Products, LLC
customer support for a R.A. number.
To optimize the performance of this product, please read these
operating instructions carefully to familiarize yourself with the basic
operations of this unit. These instructions contain important safety
information regarding the use and maintenance of this unit. Please
keep this manual with the unit, for future reference.
Quad Phase Go General Instructions
• DMX-512 Protocol Compatible (Four DMX Channels)
• RGBW
• Bright 10 Watt Quad CREE LED
• 2 Operating Modes - Sound Active & DMX Control
• Internal Microphone
• Digital Display for Address and Function Setting
• UC3 Controller (Not Included)
• Power Cord Daisy Chain
ADJ Products, LLC - www.adj.com - Quad Phase Go Instruction Manual Page 6ADJ Products, LLC - www.adj.com - Quad Phase Go Instruction Manual Page 5
Quad Phase Go Battery Precautions Quad Phase Go Battery Precautions
1. Handling of Batteries
1.1 Do Not Short Circuit the Battery
Try to never short circuit the battery. It generates a very high
current which could cause the battery to overheat which may
result in electrolyte gel leakage, harmful fumes, or explosion.
The LIR tabs may easily short-circuit by placing them on con-
ductive surface. A short circuit may lead to heat build up and
damage of the battery. An appropriate circuitry with PCM is
employed to protect accidental short circuit of the battery pack.
1.2 Mechanical shock
Droping the unit, impact hit, bending, etc. may cause failure or
shortend life of the LIR battery.
3. Other
3.1 Battery connection
1). Direct soldering of wire leads or devices to the battery is
strictly prohibited.
2). Lead tabs with pre-soldered wiring shall be spot welded to
the batteries. Direct soldering may cause damage of compo-
nents, such as separator and insulator, by heat build up.
3.2 Prevention of short circuit within a battery pack
There is enough insulation layers between wiring and the bat-
teries to provide extra safety protection. The battery pack is
constructed in a way that no short circuit will occur which may
cause smoke or re.
3.3 Do No Disassemble the Batteries
1). Never disassemble the batteries.
Doing this may cause a internal short circuit in the battery,
which may lead to harmful fumes, re, explosion, or other prob-
lems.
2). Electrolyte Gel is harmful
Electrolyte Gel should not leak from the LIR battery. Should the
electrolyte gel come into contact with the skin or eyes, ush the
area of contact immediately with fresh water and seek medical
attention immediately.
3.4 Do Not Expose the Battery to Heat or Fire
Never incinerate or dispose of the batteries in re. This may
cause an explosion, which would be very dangerous.
3.5 Do Not Expose the Battery to water or liquids
Never soak/drop the batteries in liquids such as water, seawa-
ter, drinks such as soft drinks, juices, coee or other.
3.6 Battery Replacement
For battery replacement please contact ADJ Products, LLC
customer support (800) 322-6337.
3.7 Do Not use a damaged Battery
The battery could be damaged during shipping, caused by
shock. Should the battery be found damaged, including dam-
ages to the plastic casing of the battery, deformation of the
battery package, smelling of an electrolyte, or leakage of the
electrolyte gel, or other, DO NOT use the battery. A battery with
a odor of electrolyte or a gel leakage should be placed away
from re to avoid re or explosion.
4. Battery Storage
When storing the battery, it should be stored at room tempera-
ture, with a charge of at least 50%. We recommend that during
long periods of storage that the battery be charged every 6
months. Doing this will prolong the life of the battery and will
also make sure that the battery charge does not fall below the
30% mark.
5. Other Chemical Reaction
Because batteries utilize a chemical reaction, battery perfor-
mance will deteriorate over time even if stored for a long period
of time without being used. In addition, if the various usage
conditions such as charge, discharge, ambient temperature,
etc. are not maintained within the specied ranges, the
