1. Check to be sure your power source is capable of handling the voltage

requirements of the motor, as indicated on the pump name plate.

2. These pumps are not designed or intended to be used to handle sewage

or efuent.

3. This pump has been evaluated for use with WATER only.

4. Maximum continuous operating water temperature for standard model

pumps must not exceed 104 °F (40 °C).

5. These pumps are not designed or intended to be used as a primary or

backup sump pump.

Note: Pumps with the "CSA" mark are tested to CSA Standard C22.2 No. 108.

REFER TO WARRANTY ON PAGE 2.

PERFORMANCE

Your pump is designed to effectively pump all clear storm and drain waters.

Although it will usually pass small particles suspended in water; grass, heavy

mud, sand or pea gravel can clog the pump and reduce pump performance.

This can usually be cleaned out by backushing with a garden hose through

the discharge. The normal performance that can be expected is as follows:

MODELHP

GALLONS PER HOUR AT

DISCHARGE HEIGHT ABOVE

PUMPING LEVEL

SHUT-OFF

HEAD

5 ft10 ft15 ft

421/690066036020 ft

441/41800132072020 ft

461/233002820216034 ft

DO NOT USE FOR PUMPING OILS, GASOLINE OR ANY PETROLEUM BY-PRODUCTS.

Notice to Installer: Instructions must remain with installation.

1. Inspect your pump. Occasionally, products are damaged during shipment. If the unit is damaged, contact your dealer before

using. DO NOT remove the test plug in the cover.

2. Carefully read the literature provided to familiarize yourself with specic details regarding installation and use. These materials should be retained

for future reference.

1. Make sure there is a properly installed ground fault circuit interrupter (GFCI)

protected circuit available. All pumps are furnished with provisions for

proper grounding to help protect you against the possibility of electrical

shock.

2. Make certain that the ground fault receptacle is within the reach of the

pump’s power supply cord. DO NOT USE AN EXTENSION CORD. Extension

cords that are too long or too light do not deliver sufcient voltage to the

pump motor. But, more important, they could present a safety hazard if

the insulation were to become damaged or the connection ends were to

fall into water.

3. Make sure the pump electrical supply circuit is equipped with fuses

or circuit breakers of proper capacity. A separate branch circuit is

recommended, sized according the National Electrical Code for the current

shown on the pump name plate.

4. TESTING FOR GROUND. As a safety measure, each electrical outlet should

be checked for ground using an Underwriters Laboratory Listed circuit

analyzer which will indicate if the power, neutral and ground wires are

correctly connected to your outlet. If they are not, call a qualied licensed

electrician.

5. Installation and checking of electrical circuits and hardware should only

be performed by a qualied licensed electrician.

6. FOR YOUR PROTECTION, ALWAYS DISCONNECT PUMP FROM ITS POWER

SOURCE BEFORE HANDLING.

7. These pumps are supplied with a 3-prong grounded plug to help protect

you against the possibility of electrical shock. DO NOT UNDER ANY

CIRCUMSTANCES REMOVE THE GROUND PIN. The 3-prong plug must be

inserted in a mating 3-prong fault interrupter receptacle. If the installation

does not have such a receptacle, it must be changed to the proper type,

wired, and grounded in accordance with the National Electrical Code and

all applicable local codes and ordinances.

8. Risk of electric shock. This pump has not been tested for use in swimming

pool or marine areas.

9. Prop65 Warning for California residents: Cancer and Reproductive harm-

www.P65Warnings.ca.gov.

CAUTION

SEE BELOW FOR LIST OF

CAUTIONS

SEE BELOW FOR

LIST OF WARNINGS

INSTALLATION INSTRUCTIONS

MODEL: N42, LM44, N44, N46

PREINSTALLATION CHECKLIST - ALL INSTALLATIONS

FM2427

0219

Supersedes

1016

© Copyright 2019 Zoeller

®

Co. All rights reserved.

P/N 022508

Product information presented

here reects conditions at time

of publication. Consult factory

regarding discrepancies or

inconsistencies.

MAIL TO: P.O. BOX 16347 • Louisville, KY 40256-0347

SHIP TO: 3649 Cane Run Road • Louisville, KY 40211-1961

TEL: (502) 778-2731 • 1 (800) 928-PUMP • FAX: (502) 774-3624

Visit our web site:

zoellerpumps.com

Register your

Zoeller Pump Company

Product on our website:

http://reg.zoellerpumps.com/

DATE INSTALLED:

MODEL NUMBER:
