Live view through the following channels:

Quick Setup Guide

POE IP Cameras

FREE

001-866-551-6881

If you ever have any problems setting up or using this product, call the TOLL-FREE number above for additional assistance.

Tel

Telephone Service Hours: Mon-Fri am- pm CST8:00 8:00

Please go to to download the installation software and user manual.www.zmodo.com/support-software/

Technical Support

Getting Started

Setting up for Remote Viewing

You are now ready to setup remote viewing for surveillance from any location! Before proceeding, you will

need a mobile device with iOS v6 (and up) and a valid iTunes account, or Android v2.3 and up.

Scan the QR code below or find the mobile app in the Google play store or Apple App store.

Android/iOS

To complete setup, you will need to:

Connect your mobile device to the same wireless network as your camera.

Download and open the Zsight app on your mobile device.

Open the Add Device menu, select the Scan QR Code and scan the QR code found on the outer casing of your “ ” option   

device Once successfully completed, your system will be configured for remote viewing!. 

Zsight

Download

1. Connect the IP Camera to the PoE port in PoE NVR/Switch using a network cable.  

2. Connect the power adapter to the PoE NVR/Switch. Then connect its Net port to a LAN port in the router using a network cable.

3. Connect the WAN port in your router to Internet, an indicator light will show when the camera has power and Internet access.

1. Please make sure that the router s DHCP and UPNP are enabled before connecting the camera. You can refer to the router user '

manual or consult the router manufacturer for relevant settings.

Note

Connection Steps

Note: Once you ve added the device, it will be registered with your account and others cannot add it until you delete ’

it from your device list.

Technical Support

Follow the steps below to troubleshoot common issues.

Unable to access IP Camera by 3G or Internet.

Ensure router s hotspot is turned on.’

Ensure [UPNP] is enabled on the router.

Unplug the power of camera, wait 10 seconds then power the device on again.

Unable to access Internet after your device was successfully set-up.

The Wi-Fi function will restart.

Connection Diagram

Product specificaties

Merk:	Zmodo
Categorie:	Bewakingscamera
Model:	ZP-IBG14-P
Kleur van het product:	Wit
Gewicht:	907 g
Breedte:	124 mm
Diepte:	82 mm
Hoogte:	175 mm
Soort:	IP-beveiligingscamera
Materiaal behuizing:	Aluminium
Internationale veiligheidscode (IP):	IP66
Vormfactor:	Rond
Ondersteuning voor plaatsing:	Binnen & buiten
Connectiviteitstechnologie:	Bedraad
Ethernet LAN:	Ja
Montagewijze:	Muur
Ondersteunde video-modi:	720p
Videocompressieformaten:	H.264
Type stroombron:	Power over Ethernet (PoE)
Stroomuitvoer (volt):	12
Stroomuitvoer (ampère):	2 A
Minimale belichting:	0.1 Lux
Field of view (FOV) hoek:	41 °
Aantal cameras:	1
Ingebouwde HDD:	Nee
Nachtvisie:	Ja
LED-type:	IR
Vaste focale lengte:	8 mm
Video bewegings-detectie:	Ja
Vermogensverbruik (max):	10 W
Interface:	RJ-45
Witbalans:	Auto
Ondersteunde grafische resoluties:	320 x 240,640 x 480 (VGA),1280 x 720 (HD 720)
Aantal gebruikers:	16 gebruiker(s)
Ondersteunde netwerkprotocollen:	TCP/IP, UDP, DNS/ DDNS, SMTP, UPNP, DHCP, HTTP
Web-gebaseerd management:	Ja
Ethernet interface type:	Fast Ethernet
Power over Ethernet (PoE):	Ja
Dag/nacht modus:	Ja
Maximum aperture number:	1.2
Videostreaming:	Ja
Weerbestendig:	Ja
Nachtkijker afstand:	35 m
Infrarood (IR)-afsluitingsfilter:	Ja
Aanpassing van de afbeeldingskwaliteit:	Brightness, Contrast, Saturation
Bitrate:	16 Kbps - 2 Mbps
Wifi:	Nee
Stroomverbruik (typisch):	5 W
Bedrijfstemperatuur (T-T):	-10 - 50 °C
Type waarschuwingsnotificatie:	E-mail, Snapshot alert message
