Pagina 1/9
Vari-Focal IR Dome Camera
User s Guide’
CM-S21139BG
1201-1205 ,Sangda Mansion, High Technology Park,
ShenZhen, Guangdong, China
Fax: Tel: 0755-3363-1636 0755-3363-1639
1201-1205 ,Sangda Mansion, High Technology Park,
ShenZhen, Guangdong, China
Fax: Tel: 0755-3363-1636 0755-3363-1639
SAFETY PRECAUTIONS
CAUTION
1. Do not drop objects on the product or apply strong
shock to it. Keep away from a location subject to
excessive vibration or magnetic interference.
2. Do not install in a location subject to high
temperature (over 110F), low temperature (below
0F), or high humidity. Doing so may cause fire or
electric shock.
3. If you want to relocate the already installed
product, be sure to turn off the power and then
move or reinstall it.
4. Remove the power plug from the outlet when then
there is a lightning. Neglecting to do so may cause
fire or damage to the product .
5. Keep out of direct sunlight and heat radiation
sources. It may cause fire.
6. Install it in a place with good ventilation.
7. Avoid aiming the camera directly towards
extremely bright objects such as sun, as this may
damage the CCD image sensor.
8. Apparatus shall not be exposed to dripping or
splashing and no objects filled with liquids, such as
vases, shall be placed on the apparatus.
9. The Mains plug is used as a disconnect device and
shall stay readily operable at any time.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE REAR COVER. NO USER SERVICEABLE PARTS
INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC
SHOCK DO NOT OPEN
This symbol indicates high voltage is present inside. It is
dangerous to make any kind of contact with any inside part
of this product.
This symbol alerts you that important literature concerning
operation and maintenance has been included with this
product.
WARNING
1. Be sure to use only the standard adapter that is
specified in the specification sheet. Using any
other adapter could cause fire, electrical shock, or
damage to the product
2. Incorrectly connecting the power supply or
replacing battery may cause explosion, fire,
electric shock, or damage to the product.
3. Do not connect multiple cameras to a single
adapter. Exceeding the capacity may cause
abnormal heat generation or fire .
4. Securely plug the power cord into the power
receptacle. Insecure connection may cause fire.
5. When installing the camera, fasten it securely and
firmly. A falling camera may cause personal injury
6. Do not place conductive objects (e.g.screwdrivers,
coins, metal things, etc.) or containers filled with
water on top of the camera. Doing so may cause
personal injury due to fire, electric shock, or falling
objects.
7. Do not install the unit in humid, dusty, or sooty
locations. Doing so may cause fire or electric
shock.
8. If any unusual smells or smoke come from the unit,
stop using the product. In such case, immediately
disconnect the power source and contact the
service center. Continued use in such a condition
may cause fire or electric shock.
9. If this product fails to operate normally, contact the
nearest service center. Never attempt to modify
this product in any way. (ZMODO is not liable for
problems caused by unauthorized modifications or
attempted repair.)
10. When cleaning, do not spray water directly onto
parts of the product. Doing so may cause fire or
electric shock.
1
PRODUCT OVERVIEW
Product Overview
Keep an eye on the people and places you care
about most with this color CCD dome camera.
Featuring imaging provided by a 1/3” Sony Color
CCD, it delivers good video quality, reliable
operation, a long operating life, and high value.
With 22 built in IR LEDs, this camera can capture
video in night vision mode up to 50’ away. With
4~9mm vari-focal lens, it allows you to have a
wider or further view angle. This dome camera is
designed for indoor use, and can easily be
mounted for the perfect viewing angle. BNC and
RCA connections are used for video and power.
Installation is easy and hassle free, just plug and
play.
Main Features
1/3" Sony Color CCD Image Sensor
420 TV Lines, Horizontal
4~9mm Vari-focal Lens
Signal: NTSC
Iris: Auto
Night Vision Min. Light: 0 Lux (IR On)
IR Irradiation Distance: 50' (15m)
Operation Temperature: 0F ~ 110F
Mount: Ceiling or Wall
Video Connector: BNC
Power Connector: RCA 12V DC
1) CM- 21139BG Vari-focal Color IR Dome CameraS
1) A Card
3) Screws
1) Package Box
Package includes
Please check your camera and accessories
included in the package. Those components are
as shown below:
WW W Z MO.DO.C OM
CCD C AME RA
CCD CA MERA
WW
W.Z
MODO
.CO
M
CCD CAMERA
Camera Card
Screws Package Box
2
1201-1205 ,Sangda Mansion, High Technology Park,
ShenZhen, Guangdong, China
Fax: Tel: 0755-3363-1636 0755-3363-1639
