Included:
(2) M3x12 phillips pan
(1) 1/4x20x1/4 socket cap
MFT TO PL ADAPTER (GH3/GH4)
© Wooden Camera, Inc. 2011-2015
1. Select CAMERAPL MOUNTRED MARK and , locate on
and .LENS MOUNTMFT MOUNT
2. Aligning both , fit to RED MARKSLENS MOUNT MFT
MOUNT and gently twist clockwise to lock into place.
3. Select M3 SCREWSADAPTER FOOT and .
4. Locate and align of and M3 HOLESADAPTER FOOT
, tighten with screw driver.LENS MOUNTM3 SCREWS
5. Locate 1/4-20 HOLECAMERA BODY on , select and
tighten 1/4-20 SOCKET CAPBODY through foot into .
QUICK CAGE
(DSLR)
COLLAR
LENS
MOUNT
FOOT
PL MOUNT
(GH3/GH4)
NOTE: To begin attachment of and CAMERAPL MOUNT
to , follow the instructions below.QUICK CAGE
See instructions for for full assembly.QUICK CAGE
1. Locate BASE1/4-20 and insert two low profile screws
into SCREW CHANNEL.
2. Locate 1/4-20 HOLESADAPTER FOOT on .
3. Aligning SCREW CHANNELADAPTER FOOT and , tighten
1/4-20 SCREWSHOLES to their corresponding .
BASE
SCREW
CHANNEL
1/4-20
1/4-20
