WHIRLWIND DIRECT2
IN (1/4” jack X 2)
For input of the signals from the sources. The sources may be the outputs of any type of
musical instrument or amplifier speaker output. (WARNING! When connecting to speaker outputs, the Direct2
does not supply the proper amplifier load required by most tube type amplifiers. Do not use a tube amplifier’s speaker
output alone with the Direct2. You must also have a speaker or appropriate dummy load connected to avoid possible
damage to the amplifier.
OUT (1/4” jack X 2)
A “Y” connection or “loop through” from the input.
OUTPUT 1, OUTPUT 2 (XLR jacks)
Male XLRs, which provide balanced low impedance (150 Ohms) signals suitable for
connection to balanced, low-Z equipment (mixing console, workstation, etc.)
PAD (Switch X 2)
Most instruments will operate properly when set to the OUT position. Set to the IN position
(applies an extra 20dB of attenuation) for use with very “hot” instrument signals or when
connecting the Direct2 to the speaker output of an amplier.
GND/LIFT (Switch X 2)
Disconnects the ground between each input and the corresponding XLR output when set to
the LIFT position to help eliminate hum. Ground remains connected when set to the GND
position.
This product is warranted to be free of defects in materials or workmanship to the original
purchaser for a period of 3 years from the date of purchase. Should warranty service be
required, return the unit postage paid along with the original sales receipt to:
Whirlwind Music Dist., Inc.
99 Ling Road
Rochester NY 14612
Whirlwind will, at its option, repair or replace the unit. This warranty does not cover damage
resulting from abuse, unauthorized modifications or use of the product in unintended
applications.
