Pagina 1/40

PRODUCT DESCRIPTION

1. Control panel

2. Identification plate

(do not remove)

3. Door

4. Grill

5. Light

6. Turntable

CONTROL PANEL DESCRIPTION

2 3 4 6 7

8 95

1. STOP

For stopping a function or an

audible signal, cancelling the

settings and switching off the oven.

2. MICROWAVE FUNCTION/POWER

For selecting the microwave

function and setting the required

power level.

3. GRILL FUNCTION

4. CRISP FUNCTION

5. DISPLAY

6. + / - BUTTONS

For adjusting the settings of a

function (e.g. length, weight).

7. JET DEFROST FUNCTION

8. START

For starting a function.

9. DOOR OPENING BUTTON

Owner’s Manual

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT

In order to receive a more complete assistance, please register

your product on www . whirlpool . eu/ register

PLEASE SCAN THE QR CODE ON

YOUR APPLIANCE IN ORDER TO

REACH MORE INFORMATION

Before using the appliance carefully read the Safety

Instruction.

ACCESSORIES

TURNTABLE

Placed on its support, the glass

turntable can be used with all

cooking methods.

The turntable must always be used

as a base for other containers or accessories.

TURNTABLE SUPPORT

Only use the support for the glass

turntable.

Do not rest other accessories on the

support.

WIRE RACK

This allows you to place food closer

to the grill, for perfectly browning

your dish. Place the wire rack on the

turntable, making sure that it does

not come into contact with other

surfaces.

CRISP PLATE

Only for use with the designated

functions. The Crisp plate must

always be placed in the centre of the

glass turntable and can be pre-

heated when empty, using the

special function for this purpose only. Place the food

directly on the Crisp plate.

HANDLE FOR CRISP PLATE

Useful for removing the hot Crisp

plate from the oven.

The number and the type of accessories may vary depending

on which model is purchased.

Other accessories that are not supplied can be purchased

separately from the After-sales Service.

There are a number of accessories available on the

market. Before you buy, ensure they are suitable for

microwave use and resistant to oven temperatures.

Metallic containers for food or drink should never be

used during microwave cooking.

Always ensure that foods and accessories do not

come into contact with the inside walls of the oven.

Always ensure that the turntable is able to turn freely

before starting the oven. Take care not to unseat

the turntable whilst inserting or removing other

accessories.

FUNCTIONS

MICROWAVE

For quickly cooking and reheating food or drinks.

POWER (W) RECOMMENDED FOR

750 W

Quickly reheating drinks or other foods with a high

water content or meat and vegetables.

500 W

Cooking fish, meaty sauces, or sauces containing

cheese or egg. Finishing off meat pies or pasta bakes.

350 W

Slow, gently cooking. Perfect for melting butter or

chocolate.

160 W

Defrosting frozen food or softening butter and

cheese.

0 W When using the minuteminder only.

GRILL

For browning, grilling and gratins when used

alone. We recommend turning the food during cooking.

For best results, preheat the grill for 3-5 minutes. For

quickly cooking and gratinating dishes, combines with

microwaves.

• GRILL + MW

For quickly cooking entrées (even au gratin) using

both microwaves and the grill. It is useful for

cooking food like lasagne, fish and potato gratins.

POWER (W) DURATION (min) RECOMMENDED FOR

500 14 - 18 Lasagne (400 - 500 g)

500 10 - 14 Fish (600 g)

500 40 - 50 Chicken (whole; 1-1.2 kg)

350 15 - 18 Fish gratin (600 g)

0 -

Browning only

Required accessory: Wire rack

Product specificaties

Merk:	Whirlpool
Categorie:	Oven
Model:	W67 MN840 NB
Apparaatplaatsing:	Ingebouwd
Inhoud (binnenkant):	22 l
Soort bediening:	Touch
Magnetronvermogen:	750 W
Vermogen grill:	700 W
Kleur van het product:	Zwart
Aantal vermogenniveau's:	4
Draaitafel:	Ja
Afmeting draaiplateau:	250 mm
Ingebouwd display:	Ja
Timer:	Ja
Gewicht:	21000 g
Breedte:	595 mm
Diepte:	320 mm
Hoogte:	382 mm
Netbelasting:	2000 W
Opwarmfunctie:	Ja
Grill:	Ja
Kinderslot:	Ja
Gewicht verpakking:	22500 g
Breedte verpakking:	686 mm
Diepte verpakking:	456 mm
Hoogte verpakking:	450 mm
Deur open mechanisme:	Duwen
Geïntegreerde klok:	Ja
Soort klok:	Elektronisch
Convectie koken:	Nee
Stoom koken:	Nee
Ontdooifunctie:	Ja
Installatie compartiment breedte:	560 mm
Installatie compartiment diepte:	300 mm
Automatische kookfunctie:	Ja
Installatie compartiment hoogte (min):	360 mm
Zachtsluitende deur:	Nee
Type timer:	Digitaal
Inverter technologie:	Nee
Waarschuwingssignaal:	Ja
Installatie compartiment hoogte (max):	363 mm
Type grill:	Quartz-grill
Inkorter:	Ja
Crisper-bakplaat inbegrepen:	Ja
Vochtigheidssensor:	Nee
Elektronische regeling:	Ja
Deur openen:	Opening aan zijkant
Receptenboek:	Nee
Inwendige coating:	Geverfd
Gewichtssensor:	Nee
AC-ingangsspanning:	230 V
AC-ingangsfrequentie:	50 Hz
Type product:	Grill-magnetron
Type beeldscherm:	LCD
Temperatuursensor:	Nee
Garantieperiode:	2 jaar
Multiwave-technologie:	Ja
