Owner’s Manual

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT

In order to receive a more complete assistance, please

PLEASE SCAN THE QR CODE ON

YOUR APPLIANCE IN ORDER TO

REACH MORE INFORMATION

Before using the appliance carefully read the Safety

Instruction.

PRODUCT DESCRIPTION

1. Control panel

2. Fan

3. Lamp

4. Shelf guides (the level is indicated

on the wall of the cooking

compartment)

5. Door

6. Door lock (locks the door while

automatic cleaning is in progress

and afterwards)

7. Top heating element/grill

8. Circular heating element (not

visible)

9. Identication plate (do not

remove)

10.

embossing for drinking

water

CONTROL PANEL DESCRIPTION

1 32 4 5

1. SELECTION KNOB

For switching the oven on by

selecting a function. Turn to the

position to switch the oven o.

2. LIGHT

With the oven switched on, press

to turn the oven compartment lamp

on or o.

3. SETTING THE TIME

For accessing the cooking time

settings, delayed start and timer.

For displaying the time when the

oven is o.

4. DISPLAY

5. ADJUSTMENT BUTTONS

For changing the cooking time

settings.

6. THERMOSTAT KNOB

Turn to select the temperature you

require when activating manual

functions.

Please note: Type of knob may vary from model type. If the knobs are push-activated, push down on the center of the knob to release

it from seating.

ACCESSORIES

WIRE SHELF DRIP TRAY * BAKING TRAY * SLIDING RUNNERS *

Use to cook food or as a

support for pans, cake tins

and other ovenproof items of

cookware.

Use as an oven tray for

cooking meat, sh,

vegetables, focaccia, etc. or

position underneath the wire

shelf to collect cooking juices.

Use for cooking all bread and

pastry products, but also for

roasts, sh en papillotte, etc.

To facilitate inserting or

removing accessories.

* Availble only on certain models

The number and the type of accessories may vary depending on which model is purchased.

Other accessories can be purchased separately from the After-sales Service.

INSERTING THE WIRE SHELF AND OTHER

ACCESSORIES

Insert the wire shelf onto the level you require by holding

it tilted slightly upwards and resting the raised rear side

(pointing upwards) down rst.

Then slide it horizontally along the runners as far as

possible.

Other accessories, like the baking tray, are to be inserted

horizontally, letting them slide on the runners.

SLIDING SHELVES AND SHELF GUIDES

Before using the oven remove the protective tape [a]

and then remove the protective foil [b] from the sliding

runners.

REMOVING THE SLIDING RUNNERS [c]

Pull the lower part of the sliding runner to uncouple the

lower hooks (1) and pull the the sliding runners upwards,

removing them from the upper hooks (2).

REFITTING THE SLIDING RUNNERS [d]

Hook the upper hooks on the shelf guides (1) then press

the lower part of the sliding runners against the shelf

guides, until the lower hooks are clicking (2).

[c] [d]

REMOVING AND REFITTING THE SHELF GUIDES

1. To remove the shelf guides, rmly grip the external part

of the guide, and pull it towards you to extract the support

and the two internal pins from the lodging.

2. To reposition the shelf guides, position them near the

cavity and initially insert the two pins into their lodgings.

Next, position the external part near its lodging, insert the

support, and rmly press towards the wall of the cavity to

make sure the shelf guide is properly secured.

Product specificaties

Merk:	Whirlpool
Categorie:	Oven
Model:	OMSR58RU1SB
Apparaatplaatsing:	Ingebouwd
Soort bediening:	Rotary, Touch
Vermogen grill:	2200 W
Kleur van het product:	Zwart
Ingebouwd display:	Ja
Gewicht:	26900 g
Breedte:	595 mm
Diepte:	551 mm
Hoogte:	595 mm
Grill:	Ja
Snoerlengte:	1 m
Kinderslot:	Nee
Wi-Fi-besturing:	Nee
Energie-efficiëntieklasse:	A+
Gewicht verpakking:	28200 g
Breedte verpakking:	640 mm
Diepte verpakking:	650 mm
Hoogte verpakking:	670 mm
Verlichting binnenin:	Ja
Geïntegreerde klok:	Ja
Soort klok:	Elektronisch
Convectie koken:	Ja
Stoom koken:	Ja
Rotisserie:	Nee
Totale binnen capaciteit (ovens):	71 l
Aantal ovens:	1
Installatie compartiment breedte:	568 mm
Installatie compartiment diepte:	560 mm
Installatie compartiment hoogte:	585 mm
Soort reiniging:	Hydrolytisch + Pyrolytisch
LED-indicatoren:	Nee
Stroom:	16 A
Hoeveelheid glazendeur panelen:	3
Installatie compartiment hoogte (min):	583 mm
Energieverbruik (conventioneel):	0.89 kWu
Energieverbruik (geforceerde convectie):	0.69 kWu
Koken:	Ja
Grootte oven:	Middelmaat
Soort oven:	Elektrische oven
Totaal vermogen van de oven:	- W
Netto capaciteit oven:	71 l
Magnetronbereiding:	Nee
Bakplaat afmetingen:	Ja
Zelfreinigend:	Ja
Koeldeur:	Nee
Zachtsluitende deur:	Ja
Type timer:	Digitaal
Veiligheidsklep:	Nee
Kleur handvat:	Zwart
Installatiecompartiment breedte (min):	560 mm
Instelbare thermostaat:	Ja
Aantal bakplaten:	2
Pizzafunctie:	Ja
Heteluchtgrillen:	Ja
Verlichtingslocatie:	Voorkant links
Binnenmateriaal:	Emaille
Aantal kookprogramma's:	8
Telescoopgeleiding inbegrepen:	Ja
Aantal rasters:	1
Inclusief grilrooster:	Ja
Brood maak mogelijkheid:	Nee
Ventilatieroosterfunctie:	Ja
Klaar alarm:	Nee
Ovenkookmethode:	Ventilator aangedreven
AC-ingangsspanning:	220-240 V
AC-ingangsfrequentie:	50 - 60 Hz
Type beeldscherm:	LED
Energie-efficiëntieschaal:	A+++ tot D
Brood & deeg maken programma's:	Gistend
Oven-ontdooifunctie:	Nee
Garantieperiode:	2 jaar
