INSTALLATION INSTRUCTION

LED Step and Wall Lights

WL-LED310

WARNING

IMPORTANT: NEVER attempt any work without shutting o the electricity.

- Read all instructions before installing.

- System is intended for installation by a qualied electrician in accordance with the National Electric Code,

and local regulations. Consult with local inspector to ensure compliance.

- To reduce the risk of re, electrical shock and injuries to persons, turn o power at main switch before installing

or modifying the system.

- Retain instructions for future maintenance reference.

- Not complying with instructions could result in failure of the xtures, and void the warranty.

FRAMEMOUNTED INSTALLATION INTO NEW STRUCTURES:

1. Remove all (3) adjusting brackets from mounting bracket as shown in Fig. A.

2. Use wood or sheet metal screws (by others) to attach mounting bracket to stud.

Important: Oset bracket forward to account for drywall or wood thickness. (Fig. 1a)

3. Attach the metal conduit to the canopy, then attach the canopy to the mounting bracket using the (3) screws

and (3) rubber washers (pre-installed at the factory) provided. (Figs 1b & 1c). Note: For indoor installation,

rubber washers are not required, and can be discarded. Connect building wires to the canopy in accordance

with the National Electrical Code and local ordinances.

4. Install drywall (or other material) after cutting a 3 1/8” diameter hole to allow for the recessed mounting bracket. (Fig. 1d)

5. Slip gasket onto the back of the xture. (Fig. 2)

Note: For indoor installation, gasket is not required, and can be discarded.

6. Connect the xture wires to the housing wires as follows: Black xture wire to black (Hot) housing wire,

White xture wire to white (Neutral) housing wire, and Green xture wire to Ground. (Fig. 3)

Note: Multiple xtures (up to 200) can be wired together in parallel: Hot to hot, and neutral to neutral.

7. Place all wiring and connectors back in housing and install the xture.

Note: For outdoor installation, it is recommended that the installer run a bead of clear, outdoor-rated

silicone (GE RTV-162 or equivalent) caulk between gasket or back of xture and mounting surface to

prevent seepage of water into xture.

8. Secure the xture to the housing by turning it clockwise into the canopy. (Fig. 4)

Important: Do not rotate xture more than 3 full revolutions since doing so might cause the wires to disconnect.
