WAC Lighting

www.waclighting.com

Phone (800) 526.2588 • Fax (800) 526.2585

Headquarters/Eastern Distribution Center

44 Harbor Park Drive • Port Washington, NY 11050

Phone (516) 515.5000 • Fax (516) 515.5050

Western Distribution Center

1750 Archibald Ave • Ontario, CA 91761

Phone (800) 526.2588 • Fax (800) 526.2585

WAC Lighting retains the right to modify the design of our products at any time as part of the company's continuous improvement program. JULY, 2014

INSTALLATION INSTRUCTION

007 Low Voltage Track Luminaires

HHT-007, LHT-007, JHT-007 (Available in LED)

CAUTION:

Read all instructions before installing.

Switch o power before installing or re-lamping.

Do not attempt to energize anything other than a track light xture.

All installation shall be in accordance with NEC and all local codes.

OVERVIEW:

Fixtures are designed for use on WAC “L” , “H” , “J” series track.

They may also be used on other manufacturer’s brand of track

(Consult factory for compatibility).

LAMPING:

1.Lamp (L when Use dimmable MR16 LED amp included

purchased as LED.)

2.Remove the check ring.

3. Insert the MR16 lamp by aligning the pins with the holes in

the ceramic socket, and pushing straight in.

4.Re-install the check ring.

INSTALLING ON TRACK:

1.Note the track has a groove running its length to indicate polarity.

2.Note the slant of the locking tab.

3.Insert adapter into track slot and rotate adaptor 90º so that

the low side of the locking tab faces the grooved side of the track.

4.Make sure the locking tab seats in the track slot.

5.Removal is the reverse procedure. Track heads may be positioned

anywhere along the track length.

6.Not suitable for use on wall mounted track.
