VLHDMIMAT4X2RS

4x2 HDMI 2.0 Presentation Switcher with

Matrix Outputs

User Manual

4x2 HDMI 2.0 Presentation Switcher

Preface

Read this user manual carefully before using the product. Pictures are shown in this

manual for reference only. Different models and specifications are subject to real

product.

This manual is only for operation instruction, please contact the local distributor for

maintenance assistance. The functions described in this version were updated till

October, 2019. In the constant effort to improve the product, we reserve the right to

make functions or parameters changes without notice or obligation. Please refer to the

dealers for the latest details.

Trademarks

Product model, Vivolink and its logo are trademarks of Vivolink. Any other trademarks

mentioned in this manual are acknowledged as the properties of the trademark owner.

No part of this publication may be copied or reproduced without the prior written

consent of Vivolink.

FCC Statement

This equipment generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful interference

to radio communications. It has been tested and found to comply with the limits for a

Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a commercial

installation.

Operation of this equipment in a residential area is likely to cause interference, in which

case the user at their own expense will be required to take whatever measures may be

necessary to correct the interference.

Any changes or modifications not expressly approved by the manufacture would void

the user’s authority to operate the equipment.

Product specificaties

Merk:	Vivolink
Categorie:	Schakelaar
Model:	VLHDMIMAT4X2RS
Soort bediening:	Knoppen
Ingebouwd display:	Nee
Gewicht:	860 g
Breedte:	200 mm
Diepte:	100 mm
Hoogte:	28.5 mm
Gewicht verpakking:	1050 g
Breedte verpakking:	264 mm
Diepte verpakking:	233 mm
Hoogte verpakking:	84 mm
LED-indicatoren:	Ja
Ondersteund audioformaat:	PCM
USB-connectortype:	Micro-USB
Maximum resolutie:	3840 x 2160 Pixels
Meegeleverde kabels:	IR-sensor
Inclusief AC-adapter:	Ja
Kleur behuizing:	Zwart
Aantal Ethernet LAN (RJ-45)-poorten:	1
Vermogensverbruik (max):	7.5 W
Aantal USB-aansluitingen:	1
HDCP:	Ja
HDR-ondersteuning:	Ja
RS-232 port:	1
HDMI versie:	2.0b
Aantal HDMI-invoerpoorten:	4
Audio (L,R) out:	1
Digitale audio, optische uitgang:	1
Output current:	1000 mA
Spanning:	12 V
HDCP versie:	2.2
Montagebeugels meegeleverd:	Nee
Bandbreedte:	18 Gbit/s
RJ-45 invoer ports:	1
Aantal HDMI-uitvoerpoorten:	2
Afstandsbediening inbegrepen:	Ja
AC-ingangsspanning:	100 - 240 V
AC-ingangsfrequentie:	50 - 60 Hz
Bedrijfstemperatuur (T-T):	-5 - 55 °C
Type product:	Schaalmatrixschakelaar
Code geharmoniseerd systeem (HS):	85299097
Extended display identification data (EDID):	Ja
