VITEKCCTV.COM

(888) VITEK-70

VTD-TND4RMA3

Transcendent Series 4 MegaPixel Advanced A.I. Motorized

IP Vandal Dome Camera

Image Sensor

Image Size

Resolution

Min. Illumination

Lens

Day/Night

IR LEDs

IR Distance

Video Compression

Audio Compression

Main-Stream

Bit Rate

Wide Dynamic Range (WDR)

Digital Noise Reduction (DNR)

Quality

Image Setting

Intelligent Analytics

Smart Alarm

Region of Interest (ROI)

Audio

Local Storage

Remote Viewing

Supported Browsers

Connection Protocol

Resistance

Power Input

Power Consumpt. (12VDC)

Power Consumpt. (PoE)

Working Environment

Weight

Dimensions

1/3” 4.0 Megapixel Progressive Scan CMOS

4 MegaPixel (2592 × 1520)

4 MP (2592 × 1520) / 3 MP (2304 × 1296) /

1080P (1920 × 1080) / 720P (1280 × 720) /

D1/CIF (480 × 240)

0 Lux (IR LED ON)

2.8mm~12mm Motorized Varifocal Lens

True Day/Night by ICR

3 Matrix Style IR LEDs

Up to 165’

Smart H.265 / H.265+ / H.265 / Smart H.264 /

H.264+ / H.264 / MJPEG

G.711A / G.711U

4 MP, 2K, 3MP, 1080P, 720P

(60Hz: 1 ~ 30fps; 50Hz: 1~25fps )

HFR mode: 1080P / 720P( 60Hz: 1~60fps; 50Hz: 1~50fps)

64 Kbps ~ 8 Mbps

120dB Super WDR

3D-DNR

VBR (Five Levels of Adjustment) / CBR (Adjustable)

ROI, Saturation, Brightness, Chroma, Contrast,

Sharpen, NR; Adjustable through client software or web

browser

Face Detection, Target Counting, Intrusion, Region

Entrance / Exit, Line Crossing, Scene Change, Video Blur

Motion detection, SD card error, SD card full

Each ROI to be configured separately

1 Ch. Audio In + 1 Ch. Audio Out + Built-in Mic*

Built-in micro SD card slot up to 256GB

CMS / Web Browser / Mobile (iOS/Android)

Internet Explorer, Chrome and Firefox with IE Tab

ONVIF

IP67 + IK10

12VDC / PoE

350mA (LEDs Off) / 600mA (LEDs On)

< 8W

-22° ~140° / < 95% Humidity

40.21 0z / 2.51 lbs. / 1140g

5.93” × 4.49” (151 mm × 114 mm) Dia × H

SPECIFICATIONS

*Please research local, state and federal laws regarding the

implementation of audio surveillance.

KEY FEATURES

• 1/3” 4.0 Megapixel CMOS Image Sensor

• Up to 30fps @ 4 MegaPixel (2592 × 1520)

• 2.8~12mm Motorized Varifocal Lens

• Supports Still Image Recording Function

• 3 Matrix IRs (up to 165’ IR Range)

• True Wide Dynamic Range

• True Mechanical Day/Night function by ICR

• 3D-DNR (Digital Noise Reduction)

• 1 Ch. Alarm In + 1 Ch. Alarm Out

• 1 Ch. Audio In + 1 Ch. Audio Out + Built-in Mic*

• Fully Programmable Intelligent Analytics: Face Detection, Target

Counting, Intrusion, Region Entrance / Exit, Line Crossing, Scene

Change, Video Blur

• H.265, H.264 & MJPEG Compression

• Secondary Video Output (CVBS)

• Remote Viewing via CMS, Internet Explorer, and iOS & Android Apps

• MicroSD Card Slot for Local Recording (256GB)

• IP67 Weather Resistance + IK10 Impact Rating

• Optional Junction Boxes (VT-TJB02A, VT-TJB021), Wall Mounts

(VT-TWM03, VT-TWMT-A1), Pendant Mounts (VT-TPDMT-A1 [use w/

VT-TJB02A], VT-TPDM-3 [use w/ VT-TJB021]) and In-Ceiling Semi

Flush Mount (VT-TFMT-L) [See Other Mounting Options Below]

• 12VDC & PoE (Power over Ethernet) Operation

• Available in Ivory or Charcoal Grey (VTD-TND4RMA3B)

• 3-Year Warranty

ACCESSORIES

RECORDERS

Pair with VITEK Transcendent Series

Network Recorders VT-TNR818PF,

VT-TNR1646PF, and VT-TNR3216PF

with Built-in PoE and Advanced

Analytics including Face Detection.

(888) VITEK-70 | WWW.VITEKCCTV.COM

28492 Constellation Road Valencia, CA 91355

VT-TJB02A

Optional Junction

Box for Cable

Management

VT-TWM03

Optional Wall

Mount

VT-TPDMT-A1

Universal 10”

Pendant Mount

Post Adapter -

requires

VT-TJB02A

VT-TFMT-L

Optional Semi

Flush Mount

VT-TJB021

Optional Junction

Box for Cable

Management

VT-TWMT-A1

Optional Wall

Mount

VT-TPDM-3

Pendant Mount

Post Adapter -

requires

VT-TJB021

VT-TPLMT

Universal Pole

Mount Adapter -

Ivory, reqs. VT-TWM03

VT-TCNMT

Universal Corner Mount

Adapter - Ivory, reqs.

VT-TWM03
