Specifications are subject to change without notice
AtlasSound.com
1601 JACK MCKAYBOULEVARD ENNIS, TEXAS 75119 U.S.A. • TELEPHONE: (800) 876-3332 • FAX: (800) 765-3435
©2002 ATLAS SOUND LPPrinted in U.S.A.00402 ATS001215 Rev A4/02PN 245691
INSTALLATION INSTRUCTIONS
VISIKOM PVP-24,PVP-6
MODEL PVP-24 CONTROL UNIT
MODEL PVP-6 STATION INTERFACE MODULE
The VisiKom System is designed to provide multiple independent phone lines which can each be connected
to two or more telephone stations (Model CE-2-AC or equivalent) in a common talk mode. The unique filter
circuitry used in the PVP-6 Interface Module assures absolute privacy and freedom from crosstalk between
phone lines. The PVP-24 Control unit is completely self-contained and mounts conveniently via key-hole slots
in the chassis. Each PVP-24 will accommodate up to four PVP-6 interface modules which provide six phone
lines each. (Up to 24 phone lines per system.)
The first PVP-6 Module installed in the PVP-24 (top position) plugs into the power supply via a convenient
push-on connector. Each subsequent module plugs into the one above it. Individual phone lines are brought
into the unit through wiring ports in the PVP-24 chassis.
