DLP Projector

⺩廝⩇垃媲㓌

TB2109HDH

123

54

100-240 Vac

50/60 Hz

Screws: M4 x 8 (Max. L = 8 mm)

Unit: mm

•16:9imageona4:3screen

There is 3% tolerance among these numbers due to optical component variations. It is

recommended that if you intend to permanently install the projector, you should physically

test the projection size and distance using the actual projector in situ before you permanently

install it, so as to make allowance for this projector's optical characteristics. This will help you

determine the exact mounting position so that it best suits your installation location.

•16:9imageona16:9screen

293mm

220mm 115mm

DLP Projector

⺩廝⩇垃媲㓌

TB2109HDH

3

SOURCE

ENTER

BLANK

COLOR

MODE

MEN

EXIT

BLANK

COLOR

MODE

SOURCE

E

5

MENU

EXIT

SOURCE

ENTER

BLANK

COLOR

MODE

16:9imageona16:9Screen

(a)ScreenSize(b)Projectiondistance(c)

Imageheight

(d)Verticaloffset

min.max.min.max.

inchmm

60

70

80

90

100

110

120

130

140

150

160

170

180

190

200

1524

1778

2032

2286

2540

2794

3048

3302

3556

3810

4064

4318

4572

4826

5080

inchmm

77

90

103

116

128

141

154

167

180

193

206

218

231

244

257

1958

2284

2611

2937

3263

3589

3916

4242

4568

4895

5221

5547

5874

6200

6526

inchmm

85

99

113

127

141

155

170

184

198

212

226

240

254

269

283

2154

2513

2872

3231

3589

3948

4307

4666

5025

5384

5743

6102

6461

6820

7179

inchmm

29

34

39

44

49

54

59

64

69

74

78

83

88

93

98

747

872

996

1121

1245

1370

1494

1619

1743

1868

1992

2117

2241

2366

2491

inchmm

2.4

2.7

3.1

3.5

3.9

4.3

4.7

5.1

5.5

5.9

6.3

6.7

7.1

7.5

7.8

59.8

69.7

79.7

89.7

99.6

109.6

119.5

129.5

139.5

149.4

159.4

169.4

179.3

189.3

199.2

inchmm

2.4

2.7

3.1

3.5

3.9

4.3

4.7

5.1

5.5

5.9

6.3

6.7

7.1

7.5

7.8

60

70

80

90

100

110

120

130

139

149

159

169

179

189

199

16:9imageona4:3Screen

(a)ScreenSize(b)Projectiondistance(c)

Imageheight

(d)Verticaloffset

min.max.min.max.

inchmm

60

70

80

90

100

110

120

130

140

150

160

170

180

190

200

1524

1778

2032

2286

2540

2794

3048

3302

3556

3810

4064

4318

4572

4826

5080

inchmm

71

83

94

106

118

130

142

153

165

177

189

200

212

224

236

1797

2097

2396

2696

2995

3295

3594

3894

4193

4493

4792

5092

5391

5691

5990

inchmm

78

91

104

117

130

143

156

169

182

195

208

221

233

246

259

1977

2306

2636

2965

3295

3624

3954

4283

4613

4942

5272

5601

5930

6260

6589

inchmm

27

32

36

41

45

50

54

59

63

68

72

77

81

86

90

686

800

914

1029

1143

1257

1372

1486

1600

1715

1829

1943

2057

2172

2286

inchmm

2.2

2.5

2.9

3.2

3.6

4.0

4.3

4.7

5.0

5.4

5.8

6.1

6.5

6.8

7.2

55

64

73

82

91

101

110

119

128

137

146

155

165

174

183

inchmm

2.2

2.5

2.9

3.2

3.6

4.0

4.3

4.7

5.0

5.4

5.8

6.1

6.5

6.8

7.2

55

64

73

82

91

101

110

119

128

137

146

155

165

174

183
