Pagina 1/5
Table of Contents Rev. 10/22/2020 IBC-TLT, MANUAL
Table of Contents Copyright 2020 Vestil Manufacturing Corp. Page 1 of 5
IBC-TLT-FP
Receiving Instructions
After delivery, remove the packaging from the product. Inspect the product closely to determine
whether it sustained damage during transport. If damage is discovered, record a complete description of
it on the bill of lading. If the product is undamaged, discard the packaging.
NOTE: The end-user is solely responsible for confirming that product design, use, and maintenance
comply with laws, regulations, codes, and mandatory standards applied where the product is used.
Technical Service & Replacement Parts
For answers to questions not addressed in these instructions and to order replacement parts, labels,
and accessories, call our Technical Service and Parts Department at (260) 665-7586. The Department
can also be contacted online at https://www.vestil.com/page-parts-request.php
.
Electronic Copies of Instruction Manuals
Additional copies of this instruction manual may be downloaded from
https://www.vestil.com/page-
manuals.php.
Vestil Manufacturing Corp.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
Web: www.vestilmfg.com e-mail: info@vestil.com
Table of Contents
Page
Signal Words……………………………………………….………………………………………………....
2
Safety Instructions.……………………………………………………..………………………….…………
2
Using the Container Stand…………………………………………………………………………………..
2
Exploded View and Bill of Materials………..……………………………………………………………….
3
Record of Satisfactory Condition……………………………………………………………………………
4
Inspections & Maintenance……………………………………………………………………………….....
4
Labeling Diagram.…………...………………………………………..……………....................................
4
Limited Warranty…………………………………………….………………………………………………..
5
Table of Contents Rev. 10/22/2020 IBC-TLT, MANUAL
Table of Contents Copyright 2020 Vestil Manufacturing Corp. Page 2 of 5
SIGNAL WORDS
This manual uses SIGNAL WORDS to direct the reader’s attention to important safety-related messages.
These messages describe uses of the product that could result in personal injury or property damage. Each
signal word corresponds to a specific hazard level. The following are definitions of signal words that might
appear in this manual.
Identifies a hazardous situation which, if not avoided, WILL result in DEATH or
SERIOUS INJURY. Use of this signal word is limited to the most extreme
situations.
Identifies a hazardous situation which, if not avoided, COULD result in DEATH or
SERIOUS INJURY.
Indicates a hazardous situation which, if not avoided, COULD result in MINOR or
MODERATE injury.
Identifies practices likely to result in product/property damage, such as operation that
might damage the product.
SAFETY INSTRUCTIONS
Vestil strives to identify all foreseeable hazards associated with the use of its products. However, material
handling is dangerous and no manual can address every conceivable risk. Ultimately, the most effective way
to prevent injury is to apply sound judgment whenever using this device.
Improper or careless use of this product could result in death or serious personal injuries.
• Read and understand the entire manual before assembling, installing, using or servicing the product.
Read the manual to refresh your understanding of proper use and maintenance procedures.
• DO NOT attempt to resolve any problem(s) with the product unless you are both authorized to do so and
certain that it will be safe to use afterwards.
• DO NOT modify the product in any way UNLESS you first obtain written approval from Vestil.
Unapproved modifications automatically void the LIMITED WARRANTY and might make the product unsafe
to use.
• DO NOT exceed the capacity: 4,400 pounds (2000kg). Capacity information is provided in on-product
labeling. See Label 287 in the LABELING DIAGRAM on p. 4.
• Inspect the product according to the instructions in INSPECTIONS & MAINTENANCE. DO NOT use the
product unless it is in satisfactory condition.
• DO NOT move the stand (via lift truck) until the IBC has been removed from the stand.
• DO NOT use the stand UNLESS all labels are readable & undamaged. See LABELING DIAGRAM.
USING THE CONTAINER STAND
The stand is designed to support
275gal and 300 gal. intermediate bulk
containers (ICB).
Place an ICB on the stand with the
drain (butterfly valve) opposite the
spring. The spring elevates the back
side of the container support as the
weight of the container decreases.
Elevating the back side of the ICB
causes its contents to flow towards
the drain.
The stand can be transported via
forklift. Do not transport the stand
while it is loaded. Remove the IBC
from the stand. Insert the forks into
the (2) for pockets in the frame. Tilt
the forklift mast toward the cab and
slowly and carefully drive the stand to
the offloading location.
Store the unit indoors.
Spring
Frame
weldment
Drain/Butterfly
valve
Container
support
Fork
pocket
Intermediate
bulk container
