rev. 11/13/2013 HDU-C, Manual
Copyright 2013 Vestil Manufacturing Corp. Page 1 of 11
HDU-C-SERIES STORAGE RACKS
INSTRUCTION MANUAL
Receiving instructions:
After delivery, IMMEDIATELY remove the packaging from the product in a manner that preserves the
packaging and maintains the orientation of the product in the packaging; then inspect the product closely
to determine whether it sustained damage during transport. If damage is discovered during the
inspection, immediately record a complete description of the damage on the bill of lading. If the
product is undamaged, discard the packaging.
NOTES:
1) Compliance with laws, regulations, codes, and non-voluntary standards enforced in the location where
the product is used is exclusively the responsibility of the owner/end-user.
2) VESTIL is not liable for any injury or property damage that occurs as a consequence of failing to apply either:
a) Instructions in this manual; or b) information provided on labels affixed to the product. Neither is Vestil
responsible for any consequential damages sustained as a result of failing to exercise sound judgment
while assembling, installing, using or maintaining this product.
VESTIL MANUFACTURING CORP.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
www.vestilmfg.com e-mail: sales@vestil.com
Table of Contents
Hazard identification: explanation of signal words…………………………………………………………………… 2
Safety Guidelines……………………………………………………………………………………………………….. 2
Product Specifications by Model…………………... ………………………………………………………………… 3
FIG. 1A: MDU-C exploded parts diagram…………………………………………………………………………….. 4
FIG. 1B: Upright posts…………………………………………………………………………………………………. 4
MDU-C-6 & MDU-C-8 bills of materials……………………………………………………………………………… 5
MDU-C-10 bill of materials……………………………………………………………………………………………. 6
Assembly instructions………………………………………………………………………………………………. 6-8
Maintenance………………………………………………………………………………........................................... 8
Limited warranty…………………………………………………………………………………………………………. 9
rev. 11/13/2013 HDU-C, Manual
Copyright 2013 Vestil Manufacturing Corp. Page 2 of 11
Hazard Identification--Explanation of SIGNAL WORDS
This manual uses SIGNAL WORDS to indicate the likelihood of personal injuries, as well as the probable
seriousness of those injuries, if the product is misused in the ways described. Other signal words call attention to
uses of the product likely cause property damage.
The signal words used appear below along with the meaning of each word:
Identifies a hazardous situation which, if not avoided, WILL result in DEATH or
SERIOUS INJURY. Use of this signal word is limited to the most extreme
situations.
Identifies a hazardous situation which, if not avoided, COULD result in DEATH or
SERIOUS INJURY.
Indicates a hazardous situation which, if not avoided, COULD result in MINOR or
MODERATE injury.
Identifies practices likely to result in product/property damage, such as operation that
might damage the product.
Each person who assembles, installs, uses, or maintains this product should read the entire manual in advance
and fully understand the directions. If after reading the manual you do not understand an instruction, ask
your supervisor or employer for clarification, because failure to adhere to the directions in this manual
might result in serious personal injury.
SAFETY GUIDELINES
Vestil diligently strives to identify foreseeable hazards associated with the use of its products. However, material
handling is inherently dangerous and no manual can address every conceivable risk. The end-user ultimately is
responsible for exercising sound judgment at all times.
Electrocution might result if any part of the rack system or items or materials placed on the rack contacts
electrified wires. Reduce the likelihood of electrocution by applying common sense:
DO NOT install the rack in a location where contact with electrified wires will occur.
If this product is used or assembled improperly or carelessly, people in the area might sustain serious
personal injuries or even be killed. ALWAYS use the product properly:
Failure to read and understand the entire manual before assembling, installing, loading or servicing the
product constitutes misuse. Read the manual to refresh your understanding of proper use and maintenance
procedures as necessary.
DO NOT exceed the maximum rated load.
Inspect the rack periodically (AT LEAST once per month). DO NOT continue to use the rack if the inspection reveals
structural damage. Examples of structural damage include: 1) warped, deformed, or damaged posts (uprights) or
beams; 2) cracked welds; 3) enlargement of openings that receive beam studs; 4) corrosion, severe wear, or other
condition that affects the ability of the product to support applied weight; 6) damaged, deformed or cracked cross-
supports. Immediately tag out the rack, unload it completely, and replace each part that fails to pass an inspection. DO
NOT use the product until it is fully restored to normal condition. ONLY use manufacturer-approved replacement parts.
DO NOT use the product if any unusual noise or movement is observed. If a malfunction occurs, remove the unit from
service and notify your supervisor or maintenance personnel about the issue.
All loads stored on the rack must fit within the dimensions of the rack. DO NOT store any load that hangs over the
rack.
DO NOT use the pallet rack UNLESS it is securely anchored to the ground.
ALWAYS evenly distribute and center the load on the rack.
ONLY use this rack on even, level surfaces.
DO NOT remove or obscure any label. All product labels must be readable and undamaged.
DO NOT climb or sit on the rack.
DO NOT modify the rack in any way. Unauthorized modifications automatically void the limited warranty (see p.
6) and might make the rack unsafe to use.
Proper maintenance is essential for this product to function properly and to last as long as possible.
o Always use this product in accordance with the instructions in this manual and consistent with any training relevant
to the storage of materials on racks.
o Keep the rack clean & dry.
