Pagina 1/6
1
Vestil Manufacturing Corporation
2999 North Wayne St., Angola, IN 46703
Phone (260) 665-7586 • Fax (260) 665-1339
E-mail: sales@vestil.com Website: www.vestil.com
SAFETY PRECAUTIONS
Read owner's manual completely before operating unit!
•Never exceed the maximum loading capacity of 880
pounds.
•Stand clear of load while loading and unloading.
•Load must be evenly distributed on deck to insure
stability.
•Use caution in moving a loaded unit; avoid obstructions
and floor defects.
•Always apply wheel brakes when unit is not in motion.
•Never go under deck if there is weight on unit.
•Do not continue to pump on the foot lever if the deck is
not raising.
•Remove weight before working on unit.
•Do not use brake fluid or jack oils. Use AW-32 hydraulic
oil or equivalent.
•Use only replacement parts supplied or approved by the
manufacturer.
•Consult factory before performing any modification to the
original equipment.
•Make sure all operator safety labels are in place (p.11).
RECEIVING INSTRUCTIONS
Every unit is thoroughly tested and inspected prior
to shipment. However, it is possible that the unit may incur
damage during transit. If damage is noticed when unloading,
make a note of it on the BILL OF LADING. Remove all
packing and strapping material, then inspect the unit again
for damage. IF DAMAGE IS EVIDENT, FILE A CLAIM
WITH THE CARRIER IMMEDIATELY!
WARRANTY
This product is warranted for 90 DAYS from date of
purchase to be free of manufacturing defects in material and
workmanship. The manufacturer's obligation hereunder is
limited to repairing such products during the warranty period,
provided the product is sent prepaid back to the factory.
This warranty does not cover normal wear of parts
or damage resulting from any of the following: negligent use
or misuse of the product, use or application contrary to
installation instructions, or disassembly, repair or alteration
by any person prior to authorization from a factory represen-
tative.
HEFTI-LIFT • MODEL HYD-5 & HYD-10
OWNER'S
MANUAL
Revised 1009 33-126-101
A company dedicated to solving ergonomic and material
handling problems since 1955.
HEFTI-LIFT
MODEL HYD 5 & HYD-10
Ergonomic Solutions
Contents
Safety Precautions .......................................... 1
Receiving Instructions ..................................... 1
Warranty .......................................................... 1
Parts List for HYD-5 & HYD-10 ..................... 2-3
Troubleshooting Guide for HYD-5 & HYD-10 ... 4
Warning Label Identification ............................. 5
2
PARTS LIST
HEFTI-LIFT • HYD-5 & HYD-10
PARTS IDENTIFICATION HEFTI-LIFT
MODEL HYD-5 & HYD-10
2
4
7
8
9
1
6
5
3
10
11
ITEM
NO.
1
2
3
4
5
6
7
8
9
10
11
DESCRIPTION
Chain Cover
Chain Assembly
Brake Assembly
Mast
Guide Wheel and Axle
Front Wheel and Axle
Rear Wheel and Axle
Forks Assembly
Top Deck
Front Metal Shield
Back Plastic Shield
QTY.
1
1
1
1
4
2
2
1
1
1
1
HYD-5
ENGINEER NO.
33-154-004
33-154-005
33-154-006
33-154-032
33-154-007
33-154-008
33-154-009
33-528-004
33-013-001
33-024-011
33-024-010
HYD-10
ENGINEER NO.
33-154-016
33-154-017
33-154-006
33-514-018
33-154-007
33-154-008
33-154-009
33-528-004
33-013-001
33-024-013
33-024-012
QTY.
1
2
1
1
4
2
2
1
1
1
1
3
FOOT PUMP
HEFTI-LIFT • HYD-5 & HYD-10
PARTS IDENTIFICATION
FOOT PUMP (HEFTI-LIFT)
ITEM
NO.
1
2
3
4
A
B
DESCRIPTION
Release Knob Assembly
Pump Assembly
Foot Pedal Assembly
Plunger Assembly
Pump Seal Kit
Complete Assembly
HYD-5
PART NO.
HYD5-FP01
--
HYD5-FP03
HYD5-FP04
HYD5-KITA
HYD5-KITB
QTY.
1
1
1
1
1
1
a/k Available only with purchase of kit
HYD-5
ENGINEER NO.
33-154-010
33-154-011
33-154-012
33-154-013
33-144-401
33-154-014
HYD-10
PART NO.
HYD10-FP01
--
HYD10-FP03
HYD10-FP04
HYD10-KITA
HYD10-KITB
HYD-10
ENGINEER NO.
33-154-010
33-154-018
33-154-012
33-154-013
33-144-401
33-154-022
KIT
NO.
1
2
3
4
A
B
1 2
3
4
