Rev. 2/21/2017 HDC-905, MANUAL

Copyright 2017 Vestil Manufacturing Corp. Page 1 of 19

HDC-905 Series Hydraulic Drum Crushers

Instruction Manual

HDC-905-IDC

HDC-905-HC

Receiving instructions:

After delivery, IMMEDIATELY remove the packaging from the product. Then, inspect the unit closely to determine

whether it sustained damage during transport. If damage is discovered, immediately record a complete

description of the damage on the bill of lading. If the product is undamaged, discard the packaging.

Notes:

1) Compliance with laws, regulations, codes, and non-voluntary standards enforced in the location where the product

is used is exclusively the responsibility of the owner/end-user.

2) VESTIL is not liable for any injury or property damage that occurs as a consequence of failing to apply either:

a) Instructions in this manual; or b) information provided on product labels.

Vestil Manufacturing Corp.

2999 North Wayne Street, P.O. Box 507, Angola, IN 46703

Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868

Fax: (260) 665-1339

www.vestilmfg.com e-mail: [email protected]

Table of Contents:

Signal Words……………………………………………..……………………………………………………………..………….. 2

Safe Use Recommendations……………..……………………………………………..…………………………..…….……… 2

Hydraulic circuit diagram…….……………………………………………………………………………………………………. 3

Specifications…………………………………..………………………………………………………..…………..…….………. 3

FIG. 1: HDC-905-IDC exploded parts diagram & bill of materials………...……………………………..…………………… 4

FIG. 2: HDC-905-HC exploded parts diagram & bill of materials…………………………………………………………….. 5

FIG. 3: Power unit exploded parts diagram & bill of materials………...…………………..…………………………………..6

FIG. 4: Detailed parts breakdown of manifold assembly………………

……………………………………………………… 7

Manifold, pressure switches, and valves……………….……………………………………………………………………….. 8

Hydraulic valve and pressure switch adjustment procedure………………………………………………………………….. 9

Electrical controls sequence of operation……………………………………………………………………………………… 10

Electrical system specifications…………………………………………………………………………………………………. 10

FIG. 9: Standard 3-phase electrical circuit diagram (22124024 rev. F)…………………………………………………….. 11

FIG. 10: 3-phase continuous run electrical circuit diagram (22124025 rev. C)…………………………………………….. 12

FIG. 11: Single phase 115VAC electrical circuit diagram (22124026 rev. D)……………………………………………….13

FIG. 12: Single phase 208/230VAC electrical circuit diagram (22124027 rev. E)…………………………………………. 14

Installation…………………………………………………………………………………………………………………………. 15

Loading the chamber……………………………………………………………………………………………………………... 15

Operation………….……………………………………………………………………………………………………………….. 15

Platen configurations…………………………………………………………………………………………………………… ... 16

Maintenance………………………………………………………………………………………………………………………. 16

Labeling Diagram…………….....………………………………………………………………………………………………… 17

Limited Warranty (all units except “Wash down” model HDC-905-WD)...……………..………………………………..….. 18

Limited Warranty (HDC-905-WD only)…………………………………………………………………………………………. 19
