Table of Contents Rev. 9/26/2023 H-Hoppers MANUAL
Table of Contents Copyright 2023 Vestil Manufacturing Company Page 1 of 14
H-SERIES HOPPERS
Receiving Instructions
After delivery, remove the packaging from the product. Inspect the product closely to
determine whether it sustained damage during transport. If damage is discovered, record a
complete description of it on the bill of lading. If the product is undamaged, discard the
packaging.
NOTE: The end-user is solely responsible for confirming that product design, use, and maintenance
comply with laws, regulations, codes, and mandatory standards applied where the product is
used.
Technical Service & Replacement Parts
For answers to questions not addressed in these instructions and to order replacement parts,
labels, and accessories, call our Technical Service and Parts Department at (260) 665-7586. The
department can also be contacted online at https://www.vestil.com/page-parts-request.php.
Electronic Copies of Instruction Manuals
Additional copies of this manual may be downloaded from https://www.vestil.com/page-
manuals.php.
Table of Contents
Page
Table of Figures
Page
Specifications……………….…...… 2
2
Replacement Release Handle with Cable Kit………….
2
Signal Words….………..……….…..
3
Exploded view & bill of materials: H-25 series hoppers..
4
Safety Instructions….…....………...
3
Exploded view & bill of materials: H-33 series hoppers..
5
National Standards…………......…
11
Exploded view & bill of materials: H-50 series hoppers..
6
Loading the Chute…..….….……..
11
Exploded view & bill of materials: H-75 series hoppers..
7
Using the Hopper…………...……..
11
Exploded view & bill of materials: H-100 series hoppers
8
Stacking Hoppers……...……….....
12
Exploded view & bill of materials: H-150 series hoppers
9
Record of Satisfactory Condition
12
Exploded view & bill of materials: H-200-HD………….....
10
Inspections & Maintenance…….. =
12
Labeling Diagram………………….
13
Limited Warranty…………………..
14
Vestil Manufacturing Company
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
www.vestil.com info@vestil.com
Table of Contents Rev. 9/26/2023 H-Hoppers MANUAL
Table of Contents Copyright 2023 Vestil Manufacturing Company Page 2 of 14
NOTE: If your model is not included on the webpage or you cannot access the document, contact the
Technical Service Dept. Contact information is provided on the front page of this manual.
REPLACEMENT RELEASE HANDLE WITH CABLE KIT (37-154-044)
SPECIFICATIONS
Documents that provide specifications for H-series hoppers are available online to anyone who visits Vestil’s
website. Specifications include dimensions, net weight, and capacity information. Navigate to
https://www.vestil.com/product.php?FID=445. Scroll to the Product Specifications Table portion of the page.
Find the entry for the hopper you purchased and click the button in the “PDF” column that looks like a pencil
inside a blue-bordered box. A PDF file will open. This file is the specifications document. Print a copy of the
document and keep it with your copy of this manual.
The following is an exemplar specifications document for model H-33-LD.
Item
Part no.
Description
Qty.
1
37-025-002
HANDLE, CHUTE RELEASE
1
2
37-145-001
SPECIALTY HARDWARE CABLE
1
3
43383
SWAGE SLEEVE Ø1/8" X 5/8" LONG
1
4
43403
1/4" WIRE CLAMP
2
