VP562/VP563
transition
centers outlet
over top of hood
BHSLD LINER Equipped with LED lighting. Not available with heat lamps.
WALL MOUNT LINER INSERT SPECIFICATIONS
*Recommended mounting
height is for optimum
performance.
Connection Diagram (46 3/8” Width)
Connection Diagram (28 3/8” - 40 3/8” Widths)
600 CFM B200 Dual Blower
(Top View)
900 CFM B200 Dual & B100 Single Blower
(Top View)
300 CFM B100 Single Blower
(Top View)
Electrical
1 ¾”
Centerline
of Hood
8” Outlet
Vent
Holes
5 ¼”5 ½”
Wall Side
8” Outlet
6” Outlet
5 ¼”
Wall Side
Vent
Holes
Centerline
of Hood
Electrical (2)
5 ½”
7 ⁄”
1 ⁄”
7 ⁄”
1 ¾”
6” Outlet
Vent
Hole
3 ¼”
Electrical
Centerline
of Hood
Wall Side
1 ¾”
1 ⁄”5 ¼”
10” Round10” Round
8” Round
17 ½”
2”
8” Round6” Round
VP562 Transition (Optional) For B300
(B200 Dual Blower & B100 Single Blower)
U
L
CUS
R
VP562: 10”
VP563: 12”
Connection Diagram (28 3/8” - 46 3/8” Widths)
Recommended
Mounting Height*
BHSLD
Electrical/Mechanical Specications For Blower Units
ModelVoltsAmpsHzRPM
CFM
Equivalent CFM
•
CFM
CFM
CFM
Minimum Round
Duct Size
Sones
#
B100 Single2.56015503004502732452256" (28 in.115
2
)5.4
B200 Dual4.06015506009005314804308" (50 in.115
2
)6.5
B200 Dual & B100 Single6.06015509001350804725655VP562: 10" (79 in.115
2
)6.3
Hood is available with LED lights (2 lights: 30" - 41", 3 lights: 42" - 48").
•BecausetheMagicLung
®
blowerusescentrifugalltrationratherthanconventionalbafeormeshlters,theMagicLung
®
blower can handle cooking equipment with higher cubic feet per minute (CFM) requirements and can deliver equivalent CFM much more
efcientlythanotherltrationsystems.WhencomparingtheMagicLung
®
withotherblowerunitsmadebyothermanufacturers,usethe“EquivalentCFM”.
#RatingsinaccordancewiththeStandardTestCodebytheEnergySystemsLaboratoryoftheTexasEngineeringExperimentStation.
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE Rev. 0516A
