ASSEMBLY AND INSTALLATION

INSTRUCTIONS

NOTES: 1. Before installing, consult local electrical codes for wiring and grounding requirements.

2. READ AND SAVE THESE INSTRUCTIONS.

P0140

Hardware Package (included):

WARNING:

TO AVOID RISK OF ELECTRICAL SHOCK, BE SURE TO SHUT OFF

POWER WHILE INSTALLING OR SERVICING THIS FIXTURE.

141120

Turn off the power at

fuse or circuit box.

Mounting Strap (A)

Mounting Screw (B)

Green Grounding

Screw (C)

Wire Nut (D)

Canopy (I)

Pure Shell (M)

Loop Lock (K)

Chain (L)

Hex Nut (E)

Washer (F)

Threaded Pipe(G)

Top Loop (H)

Collar (J)

Loop

Outlet Box

House Grounding Wire

Wire Nut (D)

Fixture Wire

Fixture Grounding Wire

Mounting Strap (A)

Green Grounding Screw (C)

Mounting Screw (B)

Threaded pipe(G)

Canopy (I)

Top Loop (H)

Hex Nut (E)

Washer (F)

Collar (J)

Loop Lock (K)

Loop Lock (K)

Chain (L)

Fixture

Pure Shell(M)

Socket

Bulb Type A Max.60W

(not included)

Installation Steps

1. Attach threaded pipe to the mounting strap, then secure it with a washer and hex nut.

2. Attach the mounting strap to the outlet box by using two mounting screws.
