1 947544

ISSUE 2

VIP-B 812

DUAL NETWORK STATION PORT

INTRODUCTION

The VIP-812B Dual Network Station Port allows

most loop start terminal devices to be connected

to a managed IP-based network .

SPECIFICATIONS

Access Methods

PBX, FXO Port

POTS telephone set

Features

-45 for network connection RJ

2 RJ-11 telephone connections

4 Relays with Form C contacts

Front panel activity LED

Network activity LEDs

Ringer equivalency (REN)=0.8A

2.5mm jack for external power (optional)

Power over Ethernet (PoE) 802.3af

compatible

Dimensions/Weight

2 H x 7." W x .88" D 1.70011

.1(4.cm H x 17.cm W x 3678308cm D)

Weight: 2.5 lbs. (1.13 kg)

Nominal Specications

Input Impedance: 600 Ohms

Input Level: -10dBm

Output Impedance: 600 Ohms

Output Level: - 10dBm nominal

Relay Current: 1 AMP @ 24VDC

Ring Voltage 42vRMS@20Hz

Nominal Power Requirements

Via rear panel barrel connector:

Voltage: 24VDC

Current: 325mA

Via 802.3af (PoE) Ethernet Switch:

802.3af: Class 3

These products are intended for use with a UL

Listed power source marked “Class 2” or “LPS”

rated 24VDC, or 48VDC (PoE).

PoE and all interconnected ITE are intended for

intra-building.

Environment

Temperature: 0 to +40° C

Humidity: 0 to 85% non-precipitating

Precautionary Designations

WARNING-To Reduce The Risk Of Fire Or

Electric Shock. Do Not Expose This

Apparatus To Rain Or Moisture.

AVERTISSEMENT - An de réduire les

risques d'incendie ou de décharge

électrique, évitez d'exposer le système à la

pluie ou à l'humidité.

Apparatus shall not be exposed to

drippingor splashing and no objects lled

with liquids,such as vases, shall be placed

on the apparatus.

L’appareil ne doit pas être exposé à des

égouttements et éclaboussures et aucun

Objet Rempli de liquide, comme vase, ne

doit être placé sur l’appareil.

NOTE: The telephone system referred to in

this manual is the customer premise

equipment such as an electronic key system,

a PBX or a dedicated single line telephone

sets. The VIP-812B is not intended for direct

or indirect connection to the public telephone

network. When used with a customer premise
