Pagina 1/5
1 567 947
Issue 1
VIP-480AL- SA
Syn-Apps® Compliant
IP One-Way Flexhorn
SPECIFICATIONS
Access Methods
Syn-Apps server
SIP-enabled telephone system
Features
-45 for network connection RJ
LED Status Indicator
Network activity LEDs
Power over Ethernet (PoE) 802.3af compatible
Dimensions/Weight
Horn
6.8” H x 8.3” W x 3.3” D
(17.3 cm) x (21.1 cm) x (8.4 cm)
Weight: 2.10 lbs. (0.95 kg)
Network Interface
1.62” H x 5.63” W x 3.45” D
(4.11 cm) x (14.30 cm) x (8.73 cm)
with brackets – 8.22” W (20.87 cm)
Weight: 2.10 lbs. (0.95 kg)
Nominal Power Requirements
Via 802.3af PoE Ethernet Switch: Class 3
Environment
Network Interface
Temperature: 0 to +40° C
Humidity: 0 to 85% non-precipitating
Horn:
Suitable for indoor or outdoor installation
These products are intended for use with a UL
Listed power source marked “Class 2” or “LPS”
rated 24VDC, or 48VDC (PoE).
PoE and all interconnected ITE are intended for
intra-building.
Precautionary Designations
WARNING-To Reduce The Risk Of Fire Or
Electric Shock. Do Not Expose This
Apparatus To Rain Or Moisture.
• AVERTISSEMENT - An de réduire les
risques d'incendie ou de décharge
électrique, évitez d'exposer le système à la
pluie ou à l'humidité.
Apparatus shall not be exposed to dripping
or splashing and no objects lled with
liquids, such as vases, shall be placed on
the apparatus.
• L’appareil ne doit pas être exposé à des
égouttements et éclaboussures et aucun
Objet Rempli de liquide, comme vase, ne
doit être placé sur l’appareil.
FCC Information
This equipment has been tested and found to
comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference when the equipment is operated in
a commercial environment. This equipment
generates, uses and can radiate radio
frequency energy and if not installed and used
in accordance with the instruction manual, may
cause harmful interference to radio
communications. Operation of this equipment
in a residential area may cause harmful
interference in which case the user will be
required to correct the interference at his own
expense.
2 947567
CAUTION: To reduce the risk of electric shock,
Do not remove cover (or back).
No user serviceable parts inside.
Refer servicing to qualified service personnel.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates that dangerous
voltage constituting a risk of electric
shock is present within this unit.
This symbol indicates that there are
important operating and maintenance
instructions in the literature accompanying
this unit.
INSTALLATION
Mounting
The VIP-480AL- Network Interface is designed SA
for wall or table mounting and must be within 100
meters of the network switch.
Wall: Using the wood screws and mounting
brackets provided, secure the VIP-480AL- SA
Network Interface to the wall.
Mounting (Horn)
Flush Mount using Mounting Screws
The cardboard packing material in which the horn is
shipped also serves as the template for ush
mounting. Using the template, mark location of the
opening and mounting holes on wall. Drill holes
appropriate to mounting hardware and cut out the
opening. Make appropriate wiring connections and
test the speaker for operation. Using appropriate
mounting screws (not furnished) drill and mount the
ange as shown.
UNIVERSAL BRACKET
Loosen or separate the universal bracket leaves by
loosening or removing the handle and hardware.
Using the back leaf as a template, mark the wall
through the mounting holes. Drill and mount to the
wall using appropriate screws (not furnished) or
mount directly to a junction box. Mount the
T-bracket to the back of the horn as shown using
the (2) ½ inch screws provided.
Power Connections
The only method of powering a VIP-480AL- SA
Network Interface is via a Power over Ethernet
(PoE) switch or power injector meeting the 802.3af
specication.
Make all required signal connections before
connecting to Ethernet switch or power injector
meeting the 802.3af specication.
Network Connection
The VIP-480AL- Network Interface has one SA
RJ- network connector, and one RJ-45 horn 45
connector. Use standard Ethernet patch cable to
connect the NETWORK connector of the
VIP-480AL- Network Interface to a PoE SA
Ethernet switch.
Signal Connections
Audio output connection is made from the Signal
Output. The RJ-45 connector on the horn is
connected directly to the RJ-45 Signal Output
socket on the IP Link. See Figure 1.
If additional length is required, any standard
T568B extension may be used. See Figure 2.
Status Indicator Lights
The VIP-480AL- has 2 status indication lights SA
located on network jack:
Green LED: (Link) Indicates Ethernet connection
when illuminated.
Yellow LED: (Activity) Indicator ashes to indicate
network activity.
IMPORTANT SAFETY INFORMATION
CONSIGNES DE SÉCURITÉ IMPORTANTES
1. Read these instructions.
Lisez ces instructions.
2. Keep these instructions.
Conservez ces instructions.
3. Heed all warnings.
Respectez tous les avertissements.
4. Follow all instructions.
Suivez toutes les instructions.
5. Do not use this apparatus near water.
Ne pas utiliser cet appareil près de l'eau.
6. Clean only with dry cloth.
Nettoyer avec un chion sec.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
Ne pas bloquer les ouvertures de ventilation. Installer formément aux instructions du
fabricant.
8. Do not install near any heat sources such as radiators, heat registers, stoves or other
apparatus (including ampliers) that produce heat.
Ne pas installer à proximité de sources de chaleur telles que radiateurs, registres de
chaleur, poêles ou autres appareils (y compris les amplicateurs) produisant de la chaleur.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and a
third grounding prong. The wide blade and the third prong are provided for your safety. If
the provided plug does not t into your outlet consult an electrician for replacement of the
obsolete outlet.
Ne pas contourner le dispositif de sécurité de la che polarisée ou de mise à la terre. Une
che polarisée possède deux lames dont une plus large que l'autre. Une che de terre a
deux lames et une troisième broche de mise à la terre. La lame large et la troisième
broche sont fournies pour votre sécurité. Si la che fournie ne rentre pas dans votre prise,
veuillez consulter un électricien pour le remplacement de la prise o
10.Protect the power cord from being walked on or pinched particularly enience
receptacles and the point where they exit from the apparatus.
11.Only use attachments/accessories specied by the manufacturer.
N'utilisez que des xations / accessoires spéciés par le fabricant.
12. Use only with the cart, stand, tripod, bracket or table specied
by the manufacturer or sold with the apparatus. When a cart is
used, use caution when moving the cart/apparatus combination
to avoid injury from tip-over.
Utilisez uniquement avec le chariot, stand, trépied, support ou table spécié par le
fabricant ou vendu avec l'appareil. Quand un chariot est utilisé, Soyez prudent lorsque
vous déplacez l'ensemble chariot / appareil pour éviter des blessures dues au
renversement.
13. Unplug this apparatus during lightning storms or when unused for a long period of time.
Débranchez cet appareil pendant les orages ou lorsqu'il n'est pas utilisé pendant une
longue période de temps.
14. Refer all servicing to qualied service personnel. Servicing is required when the
apparatus has been damaged in any way. Such as when the power supply cord or plug is
aged, liquid has been spilled, objects have fallen into the apparatus or the dam
apparatus has been exposed to rain or moisture and does not operate normally or has
been dropped.
Conez toute réparation à un personnel qualié. Une réparation est nécessaire lorsque
l'appareil a été endommagé de quelque façon. Par exemple lorsque le cordon
d'alimentation ou la che est endommagé, du liquide a été renversé, si des objets sont
tombés dans l'appareil ou le appareil a été exposé à la pluie ou à l'humidité et ne
fonctionne pas normalement ou s'il est tombé.
3 947567
Setup
The VIP-480AL- will automatically acquire an SA
IP address (using DHCP) and connect to the
Syn-Apps server when connected to the network
and powered up. Information specic to your
application will need to be programmed into the
Syn-Apps server. Refer to the Syn-Apps
documentation for further information.
TECHNICAL ASSISTANCE
Assistance in troubleshooting is available from the
factory. Call (540) 563-2000 and press 1 for
Technical Support or visit our website at
http://www.valcom.com.
Valcom equipment is not eld repairable. Valcom,
Inc. maintains service facilities in Roanoke,
VA.Should repairs be necessary, attach a tag to
the unit clearly stating your company name,
address, phone number, contact person and the
nature of the problem. Send the unit to:
Valcom, Inc.
Repair & Return Dept.
5614 Hollins Road
Roanoke, Va. 24019-5056
WARRANTY
Warranty information may be found on our website
at www.valcom.com/warranty.
