Issue 2

1947809

CAUTION: To reduce the risk of electric shock,

Do not remove cover.

No user serviceable parts inside.

Refer servicing to qualied service personnel.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This symbol indicates that dangerous

voltage constituting a risk of electric

shock is present within this unit.

This symbol indicates that there are

important operating and maintenance

instructions in the literature accompanying

this unit.

V-A-D IP429

IP FLUSH MOUNT SPEAKER/CLOCK ASSEMBLY

INTRODUCTION

The VIP-4A-D IP Wall Speaker with Clock enables 29

voice access and visual time indication to a single zone of

paging over an IP-based LAN/WAN. This allows page

zone extension anywhere on the network. The speaker

level is adjusted via software during set up. Clock

synchronization is initiated via connection to any Network

Time Protocol (NTP) server accessible via the network.

The enclosure is made of steel with a durable powder

coated nish. The color of the enclosure can easily be

changed to match any decor. Power is provided to the

VIP-4A-D via a Power over Ethernet (PoE) switch 29

meeting the 802.3af specication.

SPECIFICATIONS

Access Methods

• PBX, FXO Port using a VIP- 811

• POTS telephone set using a VIP-811

• PBX, FXS Port using a VIP- 821

• Valcom M Cast Page Group

• –SIPenabled telephone system

Features

-45 network connection RJ

802.3af compatible

Network Time Protocol (NTP) synchronization

Four digit time display

DIMENSIONS/WEIGHT

.3.1450” H x 100” W x 3.40” D

(.cm x 33.cm W x 8.64cm D) 369302

Weight: 4.8 LBS (27 kg) .1

Environment

Temperature: 0 to +40° C

Humidity: 0 to 85% non-precipitating

Nominal Power Requirements

Via 802.3af PoE Ethernet Switch:Class 3

Precautionary Designations

INSTALLATION

FCC Information

This equipment has been tested and found to

comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable

protection against harmful interference when

the equipment is operated in a commercial

environment. This equipment generates, uses

and can radiate radio frequency energy and if

not installed and used in accordance with the

instruction manual, may cause harmful

interference to radio communications.

Operation of this equipment in a residential area

may cause harmful interference in which case

the user will be required to correct the

interference at his own expense.
