Issue 1

1 947591

CAUTION: To reduce the risk of electric shock,

Do not remove cover (or back).

No user serviceable parts inside.

Refer servicing to qualified service personnel.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This symbol indicates that dangerous

voltage constituting a risk of electric

shock is present within this unit.

This symbol indicates that there are

important operating and maintenance

instructions in the literature accompanying

this unit.

Issue 1

VIP-4171-A12-IC

InformaCast® Compliant

IP ANALOG CLOCK / SPEAKER WALL MOUNT

INTRODUCTION

The VIP-4171-A12-IC InformaCast Compliant IP

Clock with Speaker includes a 12” Analog Clock

and a Wall Mount Speaker. The wall speaker is an

8” interior talkback speaker. This provides

synchronized time, talkback intercom and

loudspeaker paging from one IP network

connection. The 12” Analog Clock will sync its time

with the InformaCast Server.The speaker

enclosure is made of steel with a durable powder

coated finish. The color of the enclosure can be

easily changed to match any décor. A cloth

covered detachable grille is included with the

speaker. Power is provided to both the clock and

speaker via a Power over Ethernet (PoE) switch

meeting the 802.3af specification.

SPECIFICATIONS

Features

SIP Compatible

Only one network connection required

Power over Ethernet (PoE) 802.3af compatible

High Efficiency Speaker

DIMENSIONS/WEIGHT – 4 Digit

Clock – 12.81” diameter x 1.20” depth

Weight: 3.70 LBS

Speaker - 10.13” H x 12.31” W x 4.63” D

(25.73cm x 31.27cm W x 11.75cm D)

Weight: 4.25 LBS (1.9 kg)

Nominal Power Requirements

Via 802.3af PoE Ethernet Switch:Class 3

PSE (Power Sourcing Equipment) to be compliant

to IEEE 802.3af

Environment

Temperature: 0 to +40° C

Humidity: 0 to 85% non-precipitating

These products are intended for use with a UL

Listed power source marked “Class 2” or “LPS”

rated 24VDC, or 48VDC (PoE).

PoE and all interconnected ITE are intended for

intra-building.

Precautionary Designations

WARNING: To Reduce The Risk Of Fire Or

Electric Shock. Do Not Expose This

Apparatus To Rain Or Moisture.

AVERTISSEMENT: Afin de réduire les

risques d'incendie ou de décharge

électrique, évitez d'exposer le système à la

pluie ou à l'humidité.

Apparatus shall not be exposed to dripping

or splashing and no objects

filled with liquids, such as vases, shall be

placed on the apparatus.

L’appareil ne doit pas être exposé à des

égouttements et éclaboussures et

aucun Objet Rempli de liquide, comme

vase, ne doit être placé sur l’appareil.
