1 947770

CAUTION: To reduce the risk of electric shock,

Do not remove cover.

No user serviceable parts inside.

Refer servicing to qualied service personnel.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This symbol indicates that dangerous

voltage constituting a risk of electric

shock is present within this unit.

This symbol indicates that there are

important operating and maintenance

instructions in the literature accompanying

this unit.

Issue 5

VEA12AROUND , 12”

VEA16AROUND , 16”

IP PoE ANALOG CLOCKS

INTRODUCTION

The VEA12A IP PoE inch Round Analog and 12

VEA16A IP PoE 16 inch Round Analog Clocks enable

time indication, synchronization, and correction over an

IP-based LAN/WAN. This allows locating a clock

display anywhere on the network. Clock

synchronization can be programmed to sync with any

NTP (Network Time Protocol) server. The enclosure is

made of steel with a durable powder coated nish. The

color of the enclosure can easily be changed to match

any décor. Power is provided to the A12A and VE

VEA16A via a Power over Ethernet (PoE) switch

meeting the 802.3af specication.

SPECIFICATIONS

Features

-45 network connection RJ

Low-prole/semi-ush smooth surface metal case

Shatterproof, polycarbonate crystal

802.3af compatible

High Eiciency ff

Precautionary Designations

DIMENSIONS/WEIGHT

A12A VE–12.81” diameter x 1.20” depth

Weight: 3.70 LBS

A16A VE–16.81” diameter x 1.60” depth

Weight: 5.35 LBS

Nominal Power Requirements

4.5W via 802.3af PoE

Environment

Temperature: 0 to +45° C

Humidity: 0 to 85% non-precipitating

PSE (Power Sourcing Equipment) to be compliant

to IEEE 802.3af

INSTALLATION

FCC Information

This equipment has been tested and found to

comply with the limits for a Class A digital device,

pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection

against harmful interference when the equipment is

operated in a commercial environment. This

equipment generates, uses and can radiate radio

frequency energy and if not installed and used in

accordance with the instruction manual, may cause

harmful interference to radio communications.

Operation of this equipment in a residential area

may cause harmful interference in which case the

user will be required to correct the interference at

one’s own expense.
