V-CA2924

24 STATION CABLE ADAPTER

INTRODUCTION

The V-CA2924 is an adapter engineered to

make the cabling transition from an existing

Valcom V-2924A to a V-ACS45 quick and easy.

The V-CA2924 has two connections for the

Speaker and Call Switch wiring blocks used with

a V-2924A and two connections for the

Speaker/Call Switch outputs of the V-ACS45.

The V-ACS45 is then able to use the existing

speakers and call switches from a V-2924A

installation without requiring extensive field

wiring rework.

SPECIFICATIONS

Features

Two 12-zone V-ACS45 input connections

for 24 total zones

One 24-zone V-2924A speaker output

connection

One 24-zone V-2924A call switch output

connection

Four level volume control for each zone

Power Requirements

No power required

Dimensions/Weight

13” L x 9.50” H x 3.38” D

(33.02cm L x 24.13cm H x 8.58cm D)

Weight: 4.40 lbs (1.99 kg)

Environment

Temperature: 0 to +40° C

Humidity: 0 to 85% non-precipitating

These products are intended for use with a UL

Listed power source marked “Class 2” or “LPS”

rated 24VDC, or 48VDC (PoE).

PoE and all interconnected ITE are intended for

intra-building.

Precautionary Designations

WARNING-To Reduce The Risk Of Fire

Or Electric Shock. Do Not Expose This

Apparatus To Rain Or Moisture.

•AVERTISSEMENT - Afin de réduire les

risques d'incendie ou de décharge

électrique, évitez d'exposer le système à

la pluie ou à l'humidité.

Apparatus shall not be exposed to

dripping or splashing and no objects

filled with liquids, such as vases, shall

be placed on the apparatus.

•L’appareil ne doit pas être exposé à des

égouttements et éclaboussures et aucun

Objet Rempli de liquide, comme vase, ne

doit être placé sur l’appareil.

FCC Information

This equipment has been tested and found

to comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide

reasonable protection against harmful

interference when the equipment is operated

in a commercial environment. This

equipment generates, uses and can radiate

radio frequency energy and if not installed

and used in accordance with the instruction

manual, may cause harmful interference to

radio communications. Operation of this

equipment in a residential area may cause

harmful interference in which case the user

will be required to correct the interference at

one’s own expense.
