Issue 1

1 947112

CAUTION: To reduce the risk of electric shock,

Do not remove cover (or back).

No user serviceable parts inside.

Refer servicing to qualified service personnel.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This symbol indicates that dangerous

voltage constituting a risk of electric

shock is present within this unit.

This symbol indicates that there are

important operating and maintenance

instructions in the literature accompanying

this unit.

V-998-AM

LED STROBE

INTRODUCTION

These instructions contain the specifications

and information for the V-998-AM Strobe.

Features

Cost effective and versatile solution

to applications requiring visual

alerts or strobes

Wall mounting box included

24 Volt Power Supply included

Activation Methods

70 Volt amplified speaker signal

Dry contact closure

Electronic Message Sign 5V signal

See Figures 1-3 for Details

Specifications

Brightness: 110 Candela

Flash Frequency:1 per second (1 Hz)

Flash Duration: < 20 ms

Power supply voltage input: 110 Vac

Strobe minimum voltage:18 Vdc

Strobe maximum voltage: 30 Vdc

DC Current draw: 90 mA

Activation voltage requirements

Electronic message sign

40µA at 3 Volts

70 Volt audio signal

70 Volts peak

Lens color: Amber

Faceplate cover:Ivory

Dimensions/Weight

5.5”H x 5.0”W x 2.0”D

(13.9cm H x 12.7cm W x 5.08cm D)

0.62 lbs. (0.27 kg)

Environment

Temperature: 32 to 104° F (0 to 40° C),

Indoor use only

Humidity: 0 to 85% non-precipitating

Precautionary Designations

• WARNING-To Reduce The Risk Of Fire

Or Electric Shock. Do Not Expose

This Apparatus To Rain Or Moisture.

• AVERTISSEMENT - Afin de réduire les

risques d'incendie ou de décharge

électrique, évitez d'exposer le système

à la pluie ou à l'humidité.

• Apparatus shall not be exposed to

dripping or splashing and no objects

filled with liquids, such as vases, shall

be placed on the apparatus.

• L’appareil ne doit pas être exposé à

des égouttements et éclaboussures et

aucun Objet Rempli de liquide, comme

vase, ne doit être placé sur l’appareil.
