XAS010
INSTRUCTION MANUAL
Concrete Install
Wood Stud Install
Wall Bracket
EVA-1
EVA-2
M4x30mm
Bolt
Concrete Wall Anchor
Ø6x30mm
Level
STEP 1A.1
The installation distance of the two wall plates should be less
than the soundbar length (L) .
Level
<L
1/4"
(6mm)
The installation distance of the two wall plates
should be less than the soundbar length (L) .and the
distance between the drilling position and the ground is H.
EVA-1
EVA-2
Put the Soundbar onto Wall Bracket
Hang the EVA onto Wall Bracket
Centre line
<L
L
No!
1.38"(35mm)
Does your soundbar (including accessories)
weigh MORE than 30 lbs. (13.6 kg)?
Max:
30 LBS
(13.6 kg)
No? Perfect – you may continue.
Yes? This mount is NOT compatible.
Soundbarleveling adjustment
STEP 1A.2STEP 1A.3
STEP 1B.1STEP 1B.2
STEP 1B.3
STEP 2
STEP 3STEP 4
±17.5°
H
H
The distance between the drilling position and
the ground is H.
Level
H
H
