PAGE 1 OF 6 1122 IH-10385
WIRE BASKET CARTS
1-800-295-5510
uline.com
H-10385, H-10386
H-10387
1. Start with the lowest shelf. Snap the interlocking
pieces of a shelf support (wide end down) around
the post at the lowest groove where shelf is to be
located. Slide the support up or down until it snaps
onto the groove. Add a shelf support to the same
place on the remaining posts. (See Figure 2)
NOTE: NSF requires food service applications to
keep the lowest shelf at least 6" above the floor.
2. Slide post through underside of shelf until shelf slides
firmly over supports. (See Figure 3)
NOTE: Shelf should be placed so 1" lip faces
upward.
Handle x 1Basket x 1Shelf x 2
PARTS
Caster x 4Shelf Support
x 14 Sets
TOOL NEEDED
Rubber Mallet
CASTER INSTALLATION
ASSEMBLY
03
04
05
06
07
08
09
Figure 2
Figure 1
Figure 3
TO INSTALL CASTERS
1. Make sure post is positioned as shown. (See Figure 1)
2. Engage the wheel brakes to keep casters from rolling during assembly. Use
a rubber mallet to tap caster stems into posts. (See Figure 1)
Shelf
Support
Post x 4
Para Español, vea páginas 3-4.
Pour le français, consulter les pages 5-6.
