Pagina 1/155



© Copyright 2020 TRENDnet. All Rights Reserved.


TRENDnet User’s Guide
Table of Contents
i
Contents
Product Overview ........................................................................... 1
TI-RG262i / TI-RP262i ..................................................................................................... 1
Package Contents ................................................................................................ 1
TI-PG102i ....................................................................................................................... 5
Non-PoE ......................................................................................................................... 8
TI-G642i ......................................................................................................................... 8
TI-G102i ....................................................................................................................... 11
TI-G160WS ................................................................................................................... 14
TI-G160i ....................................................................................................................... 17
Switch Installation ........................................................................ 20
DIN-Rail Installation ..................................................................................................... 20
Install power supply connections ................................................................................ 21
SFP Transceiver/Optical Cable Installation .................................................................. 22
Basic IP Configuration .................................................................................................. 22
Connect additional devices to your switch .................................................................. 24
Accessing switch management interfaces ...................................... 25
Access your switch command line interface................................................................ 25
CLI Command Modes ......................................................................................... 25
Access your switch web management page ................................................................ 27
System Information....................................................................... 28
Basic Settings ................................................................................ 29
General Settings .......................................................................................................... 29
System ............................................................................................................... 29
Jumbo Frame ..................................................................................................... 30
SNTP ................................................................................................................... 31
Management Host ............................................................................................. 33
MAC Management ...................................................................................................... 35
Static MAC Settings............................................................................................ 35
Age Time Settings .............................................................................................. 37
MAC Table ......................................................................................................... 37
Port Mirror ................................................................................................................... 38
Port Settings ................................................................................................................ 40
General Settings ................................................................................................ 41
Information ........................................................................................................ 43
Advanced Settings ........................................................................ 44
Bandwidth Control ...................................................................................................... 44
QoS .................................................................................................................... 44
Rate Limitation .................................................................................................. 50
IGMP Snooping ............................................................................................................ 53
IGMP Snooping .................................................................................................. 53
Multicast Address .............................................................................................. 56
VLAN ............................................................................................................................ 59
Port Isolation ..................................................................................................... 59
802.1Q VLAN ...................................................................................................... 60
MAC VLAN ......................................................................................................... 64
DHCP Options .............................................................................................................. 65
DHCP Relay .................................................................................................................. 68
EEE (Energy Efficient Ethernet) .................................................................................... 71
ERPS (Ethernet Ring Protection Switching) ................................................................. 72
Link Aggregation .......................................................................................................... 76
Loop Detection ............................................................................................................ 81
Modbus ........................................................................................................................ 83
Power over Ethernet ................................................................................................... 87
STP ............................................................................................................................... 92
Security ...................................................................................... 101

Product specificaties

Merk:	Trendnet
Categorie:	Switches
Model:	TI-PG541i
Kleur van het product:	Zwart
Gewicht:	528 g
Breedte:	135 mm
Diepte:	120 mm
Hoogte:	31 mm
Internationale veiligheidscode (IP):	IP30
LED-indicatoren:	Ja
Type verpakking:	Doos
Snelstartgids:	Ja
Vermogensverbruik (max):	130 W
Netwerkstandaard:	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Ondersteunde beveiligingsalgoritmen:	802.1x RADIUS, HTTPS, SNMP
Web-gebaseerd management:	Ja
Rack-montage:	Nee
Redundante voeding:	Ja
Output current:	5 A
Spanning:	48 V
Mean time between failures (MTBF):	435905 uur
Quality of Service (QoS):	Ja
VLAN=ondersteuning:	Ja
Virtuele LAN-functies:	Tagged VLAN, Protocol-based VLAN
Access Control List (ACL):	Ja
Power over Ethernet (PoE):	Ja
Switchingcapaciteit:	12 Gbit/s
MAC-adrestabel:	16000 entries
10G support:	Nee
Aantal VLANs:	256
IGMP snooping:	Ja
Switch type:	Managed
Multicast-ondersteuning:	Ja
Aantal basis-switching RJ-45 Ethernet-poorten:	5
Switch-laag:	L2+
Type basis-switching RJ-45 Ethernet-poorten:	Gigabit Ethernet (10/100/1000)
Aantal moduleslots SPF:	1
Packet buffergeheugen:	128 MB
Throughput:	8.93 Mpps
Jumbo Frames ondersteuning:	Ja
Port mirroring:	Ja
Verbindingsaggregatie:	Ja
Full duplex:	Ja
DHCP-functies:	DHCP server
AC-ingangsspanning:	100 - 240 V
AC-ingangsfrequentie:	50 - 60 Hz
Bedrijfstemperatuur (T-T):	-40 - 70 °C
Relatieve vochtigheid in bedrijf (V-V):	0 - 95 procent
Code geharmoniseerd systeem (HS):	85176990
Totaal Power over Ethernet (PoE)-budget:	120 W
Aantal Power over Ethernet plus (PoE +)-poorten:	4
Jumbo frames:	10000
DIN rail bevestiging:	Ja
MIB-ondersteuning:	RFC 1213, RFC 1493, RFC 1643, RFC 1757
Broadcast stormbeheer:	Ja
Bescherming lus:	Ja
Klemmenblok inclusief:	Ja
System event log:	Ja
Ondersteunings-cd:	Ja
MAC-adres zelflerende functie:	Ja
Vermogen per poort Power over Ethernet (PoE):	30 W
Klemmenblokpoort:	Ja
Multicast MAC adrestabel:	256 entries
ARP-inspectie:	Ja
Authenticatie:	Poortgebaseerde authenticatie
