WB-RM500WALL MOUNTING BRACKET

INSTALLATION MANUAL

1. SAFETY PRECAUTIONS

• Before installation or use, be sure to carefully read all the instructions in this section for

correct and safe operation.

• Be sure to follow all the precautionary instructions in this section, which contain important

warnings and/or cautions regarding safety.

• After reading, keep this manual handy for future reference.

Indicates a potentially hazardous situation which, if mishandled, could

result in moderate or minor personal injury, and/or property damage.

CAUTION

Indicates a potentially hazardous situation which, if mishandled,

could result in death or serious personal injury.

WARNING

• Install the unit only in a location that can structurally support the weight of the unit and the

mounting bracket. Doing otherwise may result in the unit falling down and causing personal

injury and/or property damage.

•Since the unit is designed for indoor use, do not install it outdoors. If installed outdoors, the

aging of parts causes the unit to fall off, resulting in personal injury. Also, when it gets wet

with rain, there is a danger of electric shock.

•Donotuseothermethodsthanspeciedtomountthebracket.Extremeforceisappliedto

the unit and the unit could fall off, possibly resulting in personal injuries.

•Tighteneachnutandboltsecurely.Ensurethatthebrackethasnoloosejointsafter

installation to prevent accidents that could result in personal injury.

•Avoidtouchingtheunit’ssharpmetaledgetopreventinjury.

2. SPECIFICATIONS

FinishStainless steel

Dimensions146(w)x113(h)x23.9(d)mm(5.75"x4.45"x0.94")

Weight170g(0.37lb)

Accessories4x25tappingscrew(fordirectwallmounting)2.......................

M4x20machinescrew(formountingtotheswitchbox)2.......

Usable UnitConrmonTOADATALibraryathttps://www.toa-products.com/international/.

Note: Thedesignandspecicationsaresubjecttochangewithoutnoticeforimprovement.

URL:https://www.toa.jp/

133-04-00050-00

3. INSTALLING THE REMOTE MICROPHONE ON A WALL

Step 1. InstalltheWB-RM500onthewall.

Whenattachingtotheswitchbox,usethesuppliedtwoM4x20machinescrews.

Whendirectlymountingonthewallsurface,usethesuppliedtwo4x25tappingscrews.

If the supplied screws cannot be used depending on the wall materials, use the commercially

available anchor bolts according to the wall material.

Note

InstalltheWB-RM500takingatleast90mm(3.54")longspaceupfromitsdirectwall

mounting hole.

Insufcientspacewillnotallowtheinstallationoftheremotemicrophone.

Step 2. Hang the remote microphone onto

theWB-RM500.

Securely insert 4 mounting holes

in the remote microphone into 4

protrusionsoftheWB-RM500

aligning them with each other.

62.4 (2.46)69.6 (2.74)

100 (3.94)

80.5 (3.17)

100 (3.94)

29.1

(1.15)

19.4

(0.76)

83.5 (3.29)

Take at least 90 mm

(3.54") long space.

Remote microphoneWB-RM500

Direct wall mounting hole

UP mark

Unit: mm (in)

Hole for the switch box (Also used for direct wall mounting)

1

1

1

2

2

2

4 x 25 tapping screw (accessory)

Wall

M4 x 20 machine screw (accessory)

Switch box

Wall

WB-RM500

Remote microphone
