92040_ NC

HVLSRSQ-

HVLSRSQ-

HVLSRSQ-

HVLSRSQ-HVLSRSQ-

XX

XX

XX

XXXX

Hydrovive

Hydrovive

Hydrovive

Hydrovive Hydrovive

*Rough-In Guide*

*Rough-In Guide*

*Rough-In Guide*

*Rough-In Guide**Rough-In Guide*

Audio

•Amplifier: 100Watt RMS, built in Digital Signal Processor

•Built-in Bluetooth v4.2

•1” Titanium Dome Tweeter with Ferro fluid cooled aluminum voice coil2-

•4” 1- woofer

•4” passive radiator1-

Lighting

•200 Full-color luminous LED (R,G,B) ,W

•Color Changing “Mood Lighting”

•Preset Chromatherapy Chakras

•Custom user programmable “any color”

Installation Notes:

Overall size is 18 SQ .0”X 8.0 tall and requires approx. 16.7 16.7 cutout in the ””X ”

shower ceiling. The unit is self-contained as one piece and extends into the ceiling

space 8 clearance. .0” plus plumbing connectionUse a 3/8” compression fitting

and a flexible potable waterline to connect to the Rainhead. Use only potable

water and approved plumbing fittings for any shower connection. Refer to

ThermaSol Installation Instructions for full-sized template and detailed a

installation and operation instructions.

Shipping Information:

Weight……….37 lbs. ..

Length……………20 in.

Width…………....20 in.

Height…………...10 in.

Finish Chart:

Select desired finish and replace XX with code.

For any further assistance

please contact ThermaSol

at 800.776.0711 or

[email protected]om

Visit www.thermasol.com

for a complete product

definition

SPECIFICATIONS Light and Sound Rain System –

Construction……………………………………….…Machined Brass

ControllabilityThermaTouch Series Controls ………….……………

Function Lights……………….……....200 -color luminous LEDFull

Rainhead Water Supply. 3/8- 1.8GPM …..……………..”, 4080PSI,

Water Jets……………………………….………………………….…300

CEC Approved

PC = Polished Chrome

SC = Satin Chrome

PB = Polished Brass

SB = Satin Brass

AB = Antique Brass

COP = Polished Copper

ACOP = Antique Copper

PN = Polished Nickel

SN = Satin Nickel

BN = Black Nickel

MB = Matte Black

AN = Antique Nickel

PG = Polished Gold

ORB = Oil Rubbed Bronze

WHT = White

Product Specification:

A self-contained, Light and Sound Rainhead module that creates high-intensity chromatherapy lights and sounds. Rainhead is rated at 1.8

GPM Max. at 80 PSI and requires a separate diverter port with shut off valve. Powered by: provided 24V DC, 30 Watts power supply.
