AXP-100 C65 Installation Manual

Part List

108

42

4027

2210

121

68

34

26

30

A

G

MNOPQR

HIJKL

B

CDEF

Nylon Tube x5

Anchoring Mount x1

TF4 x1M3L6 Screw x3Mounting Plate x16#32 L17 Screw x5

775 Back Plate Cap x1

AXP-100 C65 x1

TY-100BP x1

Enhanced Fan Mount x1

M3L28 Screw x5M3L4 Screw x5M3L17 Screw x5

Metal Back Plate x1

LGA2011 Double Head Screw x4

Screw Nut x4

LGA 115x Screw Pillars x4

Mylar x1

AMD AM4 Platform

1

22

5

6

7

4

3

A

B

C

D

E

F

Q

M

R

Motherboard Front

www.thermalright.com

Tel: +886-2-2915-5005

Fax: +886-2-2915-5123

Email: sup[email protected]

Please follow the Installation Guide before installing this product.

Please do NOT modify or disassemble this product.

Please keep this product AWAY from children.

Please do NOT use this product for the non-PC environment.

Please do NOT apply too much thermal paste will lower heat conductivity and cooling performance!

To prevent electrical shocks, please turn o system power and unplug the power of the system before

beginning the installation.
