1
theLuxa E180 WH
1010205
theLuxa E180 BK
1010206
Motion detector
EN
307155 03
1. Basic safety information
Danger of death through electric shock or fire!
¾Installation should only be carried out by a
qualied electrician!
WARNING
•
The device conforms with EN 60669-2-1 if correctly
installed
•
IP 55 in accordance with EN 60529
2. Proper use
•
Motion detector for automatic lighting control dependent
on presence and brightness
•
Suitable for wall mounting outdoors
•
Suitable for entrances, garages, gardens, corridors, parks,
etc.
•
Only intended for installation outside of arm's reach
Disposal
Dispose of device in environmentally sound manner.
3. Connection
Disconnect power source.
Ensure device cannot be switched on.
Check absence of voltage.
Earth and bypass.
Cover or shield any adjacent live components.
4. Installation
Installation instructions
LObserve the recommended installation height of 2.5 m!
3 m
12 m
3 m
3 m
12 m
1
8
0
°
3 m
12 m
3 m
3 m
12 m
1
8
0
°
As the detector reacts to variations in temperature, avoid the
following situations:
Do not direct motion detectors at objects with highly-
reective surfaces such as mirrors, etc.
Do not install the motion detector near heat sources, such
as heating outlets, air conditioning systems, lamps, etc.
Do not direct the motion detector at objects that move in
the wind, such as curtains, large plants, etc.
Pay attention to the direction of motion during the test run.
+40°C
˚C
Disconnect power source.
0FF
230V
