MSP430x12x

MIXED SIGNAL MICROCONTROLLER

SLAS312C − JULY 2001 − REVISED SEPTEMBER 2004

1

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

DLow Supply Voltage Range 1.8 V to 3.6 V

DUltralow-Power Consumption:

− Active Mode: 200 μA at 1 MHz, 2.2 V

− Standby Mode: 0.7 μA

− Off Mode (RAM Retention): 0.1 μA

DFive Power Saving Modes

DWake-Up From Standby Mode in less

than 6 μs

D16-Bit RISC Architecture, 125 ns

Instruction Cycle Time

DBasic Clock Module Configurations:

− Various Internal Resistors

− Single External Resistor

− 32 kHz Crystal

− High Frequency Crystal

− Resonator

− External Clock Source

D16-Bit Timer_A With Three

Capture/Compare Registers

DOn-Chip Comparator for Analog Signal

Compare Function or Slope A/D

Conversion

DSerial Communication Interface (USART0)

Software-Selects Asynchronous UART or

Synchronous SPI

DSerial Onboard Programming,

No External Programming Voltage Needed

Programmable Code Protection by Security

Fuse

DFamily Members Include:

MSP430F122:4KB + 256B Flash Memory

256B RAM

MSP430F123:8KB + 256B Flash Memory

256B RAM

DAvailable in a 28-Pin Plastic Small-Outline

Wide Body (SOWB) Package, 28-Pin Plastic

Thin Shrink Small-Outline Package

(TSSOP) and 32-Pin QFN Package

DFor Complete Module Descriptions, See the

MSP430x1xx Family User’s Guide,

Literature Number SLAU049

description

The Texas Instruments MSP430 family of ultralow power microcontrollers consist of several devices featuring

different sets of peripherals targeted for various applications. The architecture, combined with five low power

modes is optimized to achieve extended battery life in portable measurement applications. The device features

a powerful 16-bit RISC CPU, 16-bit registers, and constant generators that attribute to maximum code efficiency.

The digitally controlled oscillator (DCO) allows wake-up from low-power modes to active mode in less than 6μs.

The MSP430F12x series is an ultralow-power mixed signal microcontroller with a built-in 16-bit timer and

twenty-two I/O pins. The MSP430F12x series also has a built-in communication capability using asynchronous

(UART) and synchronous (SPI) protocols in addition to a versatile analog comparator.

Typical applications include sensor systems that capture analog signals, convert them to digital values, and then

process the data and display them or transmit them to a host system. Stand alone RF sensor front end is another

area of application. The I/O port inputs provide single slope A/D conversion capability on resistive sensors.

AVAILABLE OPTIONS

PACKAGED DEVICES

T

A

PLASTIC 28-PIN SOWB

(DW)

PLASTIC 28-PIN TSSOP

(PW)

PLASTIC 32-PIN QFN

(RHB)

40°Cto85°C

MSP430F122IDWMSP430F122IPW

MSP430F122IRHB

−40°C to 85°C

MSP430F122IDW

MSP430F123IDW

MSP430F122IPW

MSP430F123IPW

MSP430F122IRHB

MSP430F123IRHB

Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of

TexasInstruments semiconductor products and disclaimers thereto appears at the end of this data sheet.

Copyright © 2001 − 2004 Texas Instruments Incorporated

PRODUCTION DATA information is current as of publication date.

Products conform to specifications per the terms of Texas Instruments

standard warranty. Production processing does not necessarily include

testing of all parameters.
