ON/OFF
ON/OFF
GND
IN
ESR
OUT
V
OUT
V
IN
Copyright © 2016, Texas Instruments Incorporated
Product
Folder
Sample &
Buy
Technical
Documents
Tools &
Software
Support &
Community
AnIMPORTANTNOTICEattheendofthisdatasheetaddressesavailability,warranty,changes,useinsafety-criticalapplications,
intellectualpropertymattersandotherimportantdisclaimers.PRODUCTIONDATA.
LP2983
SNVS170D–OCTOBER2001–REVISEDAPRIL2016
LP2983Micropower150-mAVoltageRegulatorinSOT-23Package
forOutputVoltages≤1.2VDesignedforUseWithVeryLow-ESROutputCapacitors
1
1Features
1
•OperatingInputSupplyVoltage:2.2Vto16V
•OutputCurrent:150mA
•LowZ
OUT
:0.3ΩTypical(10Hzto1MHz)
•StablewithLow-ESROutputCapacitor
•LowGroundPinCurrentatAllLoads
•OutputVoltageAccuracy1%(AGrade)
•HighPeakCurrentCapability
•WideSupplyVoltageRange(16VMaximum)
•OvertemperatureandOvercurrentProtection
•−40°Cto+125°CJunctionTemperatureRange
•RequiresMinimumExternalComponents
2Applications
•CellularPhones
•Palmtop/LaptopComputers
•PersonalDigitalAssistants(PDA)
•Camcorders,PersonalStereos,Cameras
3Description
TheLP2983isa150-mA,fixed-outputvoltage
regulatordesignedtoprovidetightvoltageregulation
inapplicationswithoutputvoltages≤1.2V.
UsinganoptimizedverticallyintegratedPNP(VIP)
process,theLP2983deliversunequaledperformance
inallcriticalspecifications:
•Groundpincurrent:Typically825µAata150-mA
load,and75µAata1-mAload.
•Enhancedstability:TheLP2983isstablewith
outputcapacitorESRdowntozero,whichallows
theuseofceramiccapacitorsontheoutput.
•Precisionoutput:1%toleranceoutputvoltages
available(Agrade).
•Smallestpossiblesize:SOT-23packageuses
absoluteminimumboardspace.
DeviceInformation
(1)
PARTNUMBERPACKAGEBODYSIZE(NOM)
LP2983SOT-23(5)2.90mm×1.60mm
(1)Forallavailablepackages,seetheorderableaddendumat
theendofthedatasheet.
space
space
space
TypicalApplication
