LMV751
www.ti.com
SNOS468E–AUGUST1999–REVISEDMARCH2013
LMV751LowNoise,LowVos,SingleOpAmp
CheckforSamples:LMV751
1
FEATURES
DESCRIPTION
TheLMV751isahighperformanceCMOS
2
•LowNoise6.5nV/√Hz
operationalamplifierintendedforapplications
•LowV
OS
(0.05mVtyp.)
requiringlownoiseandlowinputoffsetvoltage.It
•Wideband4.5MHzGBPtyp.
offersmodestbandwidthof4.5MHzforverylow
supplycurrentandisunitygainstable.
•LowSupplyCurrent500uAtyp.
•LowSupplyVoltage2.7Vto5.0V
Theoutputstageisabletodrivehighcapacitance,up
to1000pFandsourceorsink8mAoutputcurrent.
•Ground-ReferencedInputs
ItissuppliedinthespacesavingSOT-23-5Tiny
•UnityGainStable
package.
•SmallPackage
TheLMV751isdesignedtomeetthedemandsof
APPLICATIONS
smallsize,lowpower,andhighperformancerequired
bycellularphonesandsimilarbatteryoperated
•CellularPhones
portableelectronics.
•PortableEquipment
•RadioSystems
ConnectionDiagram
Figure1.SOT-23-5TopView
Figure2.VoltageNoiseFigure3.Gain/Phase
1
Pleasebeawarethatanimportantnoticeconcerningavailability,standardwarranty,anduseincriticalapplicationsof
TexasInstrumentssemiconductorproductsanddisclaimerstheretoappearsattheendofthisdatasheet.
2Alltrademarksarethepropertyoftheirrespectiveowners.
PRODUCTIONDATAinformationiscurrentasofpublicationdate.
Copyright©1999–2013,TexasInstrumentsIncorporated
ProductsconformtospecificationsperthetermsoftheTexas
Instrumentsstandardwarranty.Productionprocessingdoesnot
necessarilyincludetestingofallparameters.
